OBO BETTERMANN V-TEC VM L50 LGR V-TEC VM L50 LGR 2022955 OBO BETTERMANN Cable gland fully metric long, M50, Light grey, 7035, Polyamide, PA View larger
Images are for illustrative purposes only. Please refer to data sheet for details

V-TEC VM L50 LGR 2022955 OBO BETTERMANN Cable gland fully metric long, M50, Light grey, 7035, Polyamide, PA

V-TEC VM L50 LGR

2022955

OBO BETTERMANN

5 Pcs.

Cable gland fully metric long, M50, Light grey, 7035, Polyamide, PA Cable gland, metric thread, long, light grey. Cable gland with metric connection thread in cap nut design, suitable for junction boxes, housings, distributor cabinets in private and industrial areas. With strain relief and integrated sealing lip, tested according to DIN EN 62444. Protection class IP68. Can be used between –20°C and +65°C.

Cables > Cable gland
Gls Plastic

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

The V-TEC VM L50 LGR 2022955 OBO BETTERMANN Cable gland fully metric long, M50, Light grey, 7035, Polyamide, PA facilitates secure wire management through extended metric threaded ports on industrial enclosures. Such polyamide fittings distribute clamping force evenly around the circumference of the cable to prevent internal conductor damage.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Bend protection: no
  • CO2 Footprint (GWP) Cradle-to-Gate: 0,3035 kg CO2e / 1 Piece
  • Colour: Light grey
  • RAL 7035:
  • Dimension: M50
  • Dimension E: 60 mm
  • Dimension L max.: 54,3 mm
  • Dimension L min.: 37,5 mm
  • Dimension L1: 18 mm
  • Dimension L2: 8 mm
  • explosion-proof: no
  • Fibre-glass reinforced: no
  • Flame-resistant: acc. to VDE 0471/DIN 695 Part 2-1, test temperature 650°C
  • Flat cable gland: no
  • For Ex zone: Without
  • For Ex zone dust: Without
  • For Ex zone gas: Without

More info

▲
Bend protectionno
CO2 Footprint (GWP) Cradle-to-Gate0,3035 kg CO2e / 1 Piece
ColourLight grey; RAL 7035
DimensionM50
Dimension E60 mm
Dimension L max.54,3 mm
Dimension L min.37,5 mm
Dimension L118 mm
Dimension L28 mm
explosion-proofno
Fibre-glass reinforcedno
Flame-resistantacc. to VDE 0471/DIN 695 Part 2-1, test temperature 650°C
Flat cable glandno
For Ex zoneWithout
For Ex zone dustWithout
For Ex zone gasWithout
Halogen-freeyes
Hexagonal corner dimension60 mm
Impact-resistantno
MaterialPolyamide
Nominal thread size50
Permitted temperature range, max.65 °C
Permitted temperature range, min.-20 °C
Protection ratingIP68
Sealing area D, max.35 mm
Sealing area D, min.23 mm
Sealing insert, multipleno
Splittable glandno
Strain relief optionyes
ThreadM50 x 1,5
Thread increase1,5 mm
Thread length18 mm
Thread typeMetric
Type of sealSealing ring
Unstable torque12 Nm
Version forStraight
WAF54
With locknutno
