OBO BETTERMANN V-TEC VM L25 LGR V-TEC VM L25 LGR 2022949 OBO BETTERMANN Cable gland fully metric long, M25, Light grey, 7035, Polyamide, PA View larger
Images are for illustrative purposes only. Please refer to data sheet for details

V-TEC VM L25 LGR 2022949 OBO BETTERMANN Cable gland fully metric long, M25, Light grey, 7035, Polyamide, PA

V-TEC VM L25 LGR

2022949

OBO BETTERMANN

25 Pcs.

Cable gland fully metric long, M25, Light grey, 7035, Polyamide, PA V-TEC VM L25 LGR cable gland, long total metric M25 Polyamide, PA, Cable gland, EX zone, long metric thread, light grey. Cable glands with metric connection thread type with cap nut, for junction boxes, housing, control cabinets in the private and industrial sector. With traction relief and integrated sealing lip, tested according to DIN EN 62444. IP68 protection class. It can be used between -20°C and +65°C.

Cables > Cable gland
Gls Plastic

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Designed with an extended metric thread length, the Obo Bettermann V-TEC VM L25 LGR (2022949) operates as a fully metric long cable gland. These specialized fittings accommodate thicker enclosure walls or extra mounting hardware while delivering dependable sealing and strain relief for incoming cables.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Thread type (EF001758): Metric
  • Nominal thread size metric/PG (EF007839): 25
  • Pitch thread (EF003712): 1.5 mm
  • Thread length (EF000368): 15 mm
  • Wrench width (EF000177): 29 mm
  • Hexagon angular dimension (EF005268): 32 mm
  • Suitable for cable diameter (EF005466): 9 mm
  • Material (EF002169): Plastic
  • Material quality (EF001257): Polyamide (PA)
  • Halogen free (EF000025): Yes
  • Degree of protection (IP) (EF005474): IP68
  • Shock resistant (EF000084): No
  • Colour (EF000007): Grey
  • RAL-number (EF000116): 7035
  • Bend radius protection/trumpet flare (EF000734): No
  • With locknut (EF005049): No

More info

▲
The quickest and most convenient way of providing strain relief and tightness with cable glands on junction boxes and housings is with the tried-and-trusted V-TEC VM cable glands from OBO. With the integrated sealing lip and the special OBO lamella technology protection class IP68 is achieved. Strain relief and tightness have been tested to DIN en 50262.
The connecting threads are metric and are therefore suitable for universal use. Eleven screwed in place, the fitting is there for ever, as the optimum thread adjustment with the right pitch ensures permanent resistance to shaking.
Applications: From private housing with junction boxes up to industrial applications in the distributor cabinet.
Temperature range: -20 °C to +65 °C.
