OBO BETTERMANN V-TEC L PG7 LGR V-TEC L PG7 LGR 2024284 OBO BETTERMANN Cable gland with long connection thread, PG7, Light grey, 7035, Polya.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

V-TEC L PG7 LGR 2024284 OBO BETTERMANN Cable gland with long connection thread, PG7, Light grey, 7035, Polya..

V-TEC L PG7 LGR

2024284

OBO BETTERMANN

50 Pcs.

Cable gland with long connection thread, PG7, Light grey, 7035, Polyamide, PA Cable gland, long PG thread, light grey. Cable gland with PG connection thread in cap nut design, suitable for junction boxes, housings, distributor boxes in private and industrial areas. With strain relief and integrated sealing lip, tested according to DIN EN 62444. Protection class IP68. Can be used between –20°C and +65°C.

Cables > Cable gland
Gls Plastic

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Constructed with an extended connection thread, the V-TEC L PG7 LGR cable gland by Obo Bettermann ensures reliable strain relief and sealing for small-diameter cables entering control panels. Cable glands are fundamental accessories deployed across all automation sectors to safeguard internal wiring terminations. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Bend protection: no
  • CO2 Footprint (GWP) Cradle-to-Gate: 0,0307 kg CO2e / 1 Piece
  • Colour: Light grey; RAL 7035
  • Dimension: PG7
  • Dimension E: 16,5 mm
  • Dimension L max.: 23 mm
  • Dimension L min.: 18 mm
  • Dimension L1: 15 mm
  • Dimension L2: 5 mm
  • Dimension L3: 12,6 mm
  • explosion-proof: no
  • Fibre-glass reinforced: no
  • Flat cable gland: no
  • For Ex zone: Without
  • For Ex zone dust: Without
  • For Ex zone gas: Without

More info

▲
Bend protectionno
CO2 Footprint (GWP) Cradle-to-Gate0,0307 kg CO2e / 1 Piece
ColourLight grey; RAL 7035
DimensionPG7
Dimension E16,5 mm
Dimension L max.23 mm
Dimension L min.18 mm
Dimension L115 mm
Dimension L25 mm
Dimension L312,6 mm
explosion-proofno
Fibre-glass reinforcedno
Flat cable glandno
For Ex zoneWithout
For Ex zone dustWithout
For Ex zone gasWithout
Halogen-freeyes
Hexagonal corner dimension16,5 mm
Impact-resistantno
MaterialPolyamide
Nominal thread size7
Permitted temperature range, max.65 °C
Permitted temperature range, min.-20 °C
Protection ratingIP68
Sealing area D, max.6,5 mm
Sealing area D, min.2,5 mm
Sealing insert, multipleno
Splittable glandno
Strain relief optionyes
ThreadPg 7
Thread increase1,5 mm
Thread length15 mm
Thread typePG
Type of sealSealing ring
Unstable torque1,67 Nm
Version forStraight
WAF15
With locknutno
