V10 COMPACT 150 5093378 OBO BETTERMANN V10 COMPACT V10 COMPACT 150
V10 COMPACT 150
5093378
OBO BETTERMANN
1 Pcs.
V10 COMPACT V10 COMPACT 150
V10 Compact V10 COMPACT 150, 150V,
Surge arrester V10 Compact 150 V. Surge protective device, compact module, type 2+3• Surge protection in sub-distributors to VDE 0100-443 (IEC 60364-4-44)• Arresting capacity up to 60 kA (8/20) in total• Integrated 3+1 solution for TN and TT network systems on 45 mm module width • High-performance varistor technology• Incl. thermal and dynamic cut-off unit and visual function displayApplication: Sub/storey distribution as well as device protection in rotational current systems.
Automation > Surge protection device for power supply systems
TBS Transient and lightning protection systems - OBO BETTERMANN
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲| Arrester surge current (8/20 µs) [total] | 60 kA |
|---|---|
| Blow-out | no |
| CO2 Footprint (GWP) Cradle-to-Gate | 0,7051 kg CO2e / 1 Piece |
| Conductor cross-section, rigid (single-wire/multiwire), max. | 10 mm² |
| Conductor cross-section, rigid (single-wire/multiwire), min. | 2,5 mm² |
| Dimension | 150V |
| Follow current quenching capacity (eff) [N-PE] | 0,1 kA |
| Installation type | DIN rail 35 mm |
| Integrated back-up fuse | no |
| Lightning protection zone LPZ | 1→3 |
| Max. mains-side overcurrent protection | 63 |
| Maximum back-up fuse | 63 A |
| Maximum continuous voltage AC | 150 V |
| Maximum discharge current (8/20 μs) | 20 kA |
| Network form | Other |
| Nominal discharge current (8/20 µs) | 10 kA |
| Nominal voltage AC (50/60 Hz) | 120 V |
| Operating temperature, max. | 80 °C |
| Operating temperature, min. | -40 °C |
|---|---|
| Permitted temperature range, max. | 80 °C |
| Permitted temperature range, min. | -40 °C |
| Pole version | 3+N/PE |
| Protection rating | IP20 |
| Remote signalling | no |
| Response time | <25 ns |
| Signalling on device | Visual |
| SPD to EN 61643-11 | Type 2+3 |
| SPD to IEC 61643-1 | Class II+III |
| Test class, type 2 | yes |
| Test class, type 3 | yes |
| TN network form | yes |
| TN-C-S network form | yes |
| TN-S network form | yes |
| TT network form | yes |
| Version for | 3+NPE |
| Feature Name | Feature Value |
|---|---|
| System configuration TN (EF009928) | Yes |
| System configuration TN-C-S (EF009933) | Yes |
| System configuration TN-S (EF009930) | Yes |
| System configuration TT (EF009931) | Yes |
| Nominal discharge surge current (8/20) (EF004214) | 10 kA |
| Max. discharge surge current (8/20) (EF012274) | 20 kA |
| Nominal voltage AC (EF004220) | 120 V |
| Max. continuous voltage AC (EF004198) | 150 V |
| Voltage protection level (EF003525) | 0.7 kV |
| Integrated backup fuse (EF008797) | No |
| Mounting method (EF000003) | DIN rail (top hat rail) 35 mm |
| Construction size (EF002566) | Other |
| Max. conductor cross section solid (solid, stranded) (EF008827) | 10 mm² |
| Signalling at the device (EF004241) | Optic |
| Category type 2 (EF004230) | Yes |
| Degree of protection (IP) (EF005474) | IP20 |
