RKR2 4SL2 V2 20 7409072 OBO BETTERMANN Heavy-duty cassette blank, 20 kN, 200x200mm, Stainless steel, grade 3..
RKR2 4SL2 V2 20
7409072
OBO BETTERMANN
1 Pcs.
Heavy-duty cassette blank, 20 kN, 200x200mm, Stainless steel, grade 304, VA, 1.4301
Height-adjustable heavy-duty cassette, blank, RKRSL, nominal size R4, stainless steel. Round, "blank", heavy-duty cassette of nominal size R4 for the creation of an inspection opening in trunking systems, raised and cavity floors, in dry or wet-care floors for indoor use. Load class 2 to 20 kN. Only suitable for smooth floor coverings.Height-adjustable heavy-duty cassette as a blind cassette with a load bearing capacity of 2–20 kN, 2-compartment. 2 APMT2 cover plates can be installed. For the installation of 2 UT3 universal supports for 4 individual installation devices with support ring/support clamp or 6 Modul 45 devices for indoor use.
Automation > Levelling cassette for duct mounting, raised and underfloor installation
Other
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲| Cable outlet version | No cable outlet |
|---|---|
| CO2 Footprint (GWP) Cradle-to-Gate | 12,8304 kg CO2e / 1 Piece |
| Decouplable | no |
| Device support to accept mounting boxes | yes |
| Dimension | Ø215mm |
| Dimension h | 105 mm |
| Floor care | Wet |
| Floor covering thickness | 20 mm |
| Floor height, max. | 155 mm |
| Floor height, min. | 105 mm |
| Heavy load class | 20 kN (OBO SL2) |
| Heavy-duty version | yes |
| Height-adjustment range, max. | 155 mm |
| Height-adjustment range, min. | 105 mm |
|---|---|
| Installation depth | 105 mm |
| Installation diameter | 215 |
| Installation system type | UT3 |
| Material | Stainless steel 1.4301 |
| Nominal size for device installation units | R4 |
| Protection rating (IP) when unused | IP44 |
| Protection rating (IP) when used | IP00 |
| Protection rating IK code | IK10 |
| Suitable for cavity floor installation | yes |
| Suitable for raised floor installation | yes |
| Version for | Round |
