OBO BETTERMANN 280 8-10 280 8-10 5320011 OBO BETTERMANN End piece , Electrogalvanised, DIN 50961, Die-cast zinc, Zn View larger
Images are for illustrative purposes only. Please refer to data sheet for details

280 8-10 5320011 OBO BETTERMANN End piece , Electrogalvanised, DIN 50961, Die-cast zinc, Zn

280 8-10

5320011

OBO BETTERMANN

20 Pcs.

End piece , Electrogalvanised, DIN 50961, Die-cast zinc, Zn End piece. • With Ø 11 mm fastening hole• 2 hexagonal bolts M6 x 12, bolts made of hot galvanised steel or of VA• Clamping block made of die-cast zinc or copper-plated die-cast zinc

Connectors > Connector for lightning protection
Surge , external

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

An end piece terminal provides a secure termination point for round conductors at the extremities of grounding and lightning protection layouts. It secures the final run of cable while protecting the installation from environmental degradation. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • CO2 Footprint (GWP) Cradle-to-Gate: 0,2995 kg CO2e / 1 Piece
  • Dimension: 60x30x20
  • Fastening hole: 11 mm
  • Fit: Rd 8-10 mm
  • Intermediate plate: no
  • Material: Die-cast zinc
  • Suitable for connection: Round conductor Rd 8–10 / Rd 8–10
  • Surface: Electrogalvanized
  • Type of connector: End piece
  • Type of fastening screw: Hexagonal bolt

More info

▲
CO2 Footprint (GWP) Cradle-to-Gate0,2995 kg CO2e / 1 Piece
Dimension60x30x20
Fastening hole11 mm
FitRd 8-10 mm
Intermediate plateno
MaterialDie-cast zinc
Suitable for connectionRound conductor Rd 8–10 / Rd 8–10
SurfaceElectrogalvanized
Type of connectorEnd piece
Type of fastening screwHexagonal bolt
