OBO BETTERMANN V-TEC VM40+ OR V-TEC VM40+ OR 7205669 OBO BETTERMANN Cable gland with locknut, M40, Pastel orange, 2003, Polyamide, fibregl.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

V-TEC VM40+ OR 7205669 OBO BETTERMANN Cable gland with locknut, M40, Pastel orange, 2003, Polyamide, fibregl..

V-TEC VM40+ OR

7205669

OBO BETTERMANN

10 Pcs.

Cable gland with locknut, M40, Pastel orange, 2003, Polyamide, fibreglass reinforced, PA/GF V-TEC VM40+ OR cable gland, with M40 Polyamide lock nut, PA, Cable glands with lock nuts. Robust gland type with cap nut with metric connection thread according to IEC 423, with pre-assembled lock nut included. For situations where high tightness is required. Tensile relief, torsion protection and tightness along the entire tightening area. Polychloroprene/acrylonitrile-butadiene rubber gasket. Sealing lip in the intermediate fittings, no additional gasket is required for the connection thread. With VDE approval according to DIN EN 50262, IP 68 protection degree with 5 bar 1 h. For electrical function maintenance according to DIN 4102 part 12 in combination with the FireBox T series junction boxes. Color: pale orange.

Cables > Cable gland
BSS fire protection systems - OBO BETTERMANN

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
Robust cap nut cable gland with metric connecting thread to IEC 423, including pre-mounted locknut.
For high tightness requirements. Strain relief, wringing protection and tightness over the whole clamping area. Sealing ring made of polychloroprene/acrylonitrile butadiene rubber. Moulded shaped sealing lip on intermediate support, no connection thread sealing ring required.
VDE-tested according to DIN en 50262, protection rating IP68 at 5 bar for 1 hr.
For electrical function maintenance according to DIN 4102 Part 12 in connection with the junction boxes of the FireBox T series.
Colour: Pastel orange.
ETIM for 7205669 Cable glands and cable entry products (EC000441)
Feature Name Feature Value
Thread type (EF001758) Metric
Pitch thread (EF003712) 1.5 mm
Thread length (EF000368) 11 mm
Wrench width (EF000177) 44 mm
Suitable for cable diameter (EF005466) 16 mm
Material (EF002169) Plastic
Material quality (EF001257) Polyamide (PA)
Halogen free (EF000025) Yes
Degree of protection (IP) (EF005474) IP68
Shock resistant (EF000084) No
Colour (EF000007) Orange
RAL-number (EF000116) 2003
Bend radius protection/trumpet flare (EF000734) No
With locknut (EF005049) Yes
Multi seal area (EF005004) No
Flat cable coupling (EF004685) No
With strain relief (EF000878) Yes
Separable screw gland (EF005337) No
Operating temperature (EF001742) -20 °C
For Ex-zone gas (EF005728) None
For Ex-zone dust (EF008404) None
