OBO BETTERMANN V-TEC VM32+ OR V-TEC VM32+ OR 7205666 OBO BETTERMANN Cable gland with locknut, M32, Pastel orange, 2003, Polyamide, fibregl.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

V-TEC VM32+ OR 7205666 OBO BETTERMANN Cable gland with locknut, M32, Pastel orange, 2003, Polyamide, fibregl..

V-TEC VM32+ OR

7205666

OBO BETTERMANN

10 Pcs.

Cable gland with locknut, M32, Pastel orange, 2003, Polyamide, fibreglass reinforced, PA/GF V-TEC VM32+ OR cable gland, with M32 Polyamide lock nut, PA, Cable glands with lock nuts. Robust gland type with cap nut with metric connection thread according to IEC 423, with pre-assembled lock nut included. For situations where high tightness is required. Tensile relief, torsion protection and tightness along the entire tightening area. Polychloroprene/acrylonitrile-butadiene rubber gasket. Sealing lip in the intermediate fittings, no additional gasket is required for the connection thread. With VDE approval according to DIN EN 50262, IP 68 protection degree with 5 bar 1 h. For electrical function maintenance according to DIN 4102 part 12 in combination with the FireBox T series junction boxes. Color: pale orange.

Cables > Cable gland
BSS fire protection systems - OBO BETTERMANN

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Obo Bettermann V-TEC VM32+ OR cable gland with locknut maintains robust structural and environmental barriers for conductors passing into automated machinery housings. Supplied locknuts ensure a secure, vibration-resistant mount on panels.

Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Thread type (EF001758): Metric
  • Pitch thread (EF003712): 1.5 mm
  • Thread length (EF000368): 11 mm
  • Wrench width (EF000177): 36 mm
  • Suitable for cable diameter (EF005466): 15 mm
  • Material (EF002169): Plastic
  • Material quality (EF001257): Polyamide (PA)
  • Halogen free (EF000025): Yes
  • Degree of protection (IP) (EF005474): IP68
  • Shock resistant (EF000084): No
  • Colour (EF000007): Orange
  • RAL-number (EF000116): 2003
  • Bend radius protection/trumpet flare (EF000734): No
  • With locknut (EF005049): Yes
  • Multi seal area (EF005004): No
  • Flat cable coupling (EF004685): No

More info

▲
Robust cap nut cable gland with metric connecting thread to IEC 423, including pre-mounted locknut.
For high tightness requirements. Strain relief, wringing protection and tightness over the whole clamping area. Sealing ring made of polychloroprene/acrylonitrile butadiene rubber. Moulded shaped sealing lip on intermediate support, no connection thread sealing ring required.
VDE-tested according to DIN en 50262, protection rating IP68 at 5 bar for 1 hr.
For electrical function maintenance according to DIN 4102 Part 12 in connection with the junction boxes of the FireBox T series.
Colour: Pastel orange.

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
