View larger
Images are for illustrative purposes only. Please refer to data sheet for details
V-TEC VM25+ OR 7205663 OBO BETTERMANN Cable gland with locknut, M25, Pastel orange, 2003, Polyamide, fibregl..
V-TEC VM25+ OR
7205663
OBO BETTERMANN
10 Pcs.
Cable gland with locknut, M25, Pastel orange, 2003, Polyamide, fibreglass reinforced, PA/GF
Cable gland with locknut as a set. Robust cap nut cable gland with metric connecting thread to IEC 423, including pre-mounted locknut.For high tightness requirements. Strain relief, torsion protection and tightness over the whole clamping area. Sealing ring made of polychloroprene/acrylonitrile butadiene rubber. Moulded shaped sealing lip on intermediate support, no connection thread sealing ring required.VDE-tested according to DIN EN 50262, protection rating IP68 at 5 bar for 1 hr.For maintenance of electrical function according to DIN 4102 Part 12 in connection with the closed junction boxes of the FireBox T series.Colour: Pastel orange.
Cables > Cable gland
BSS fire protection systems - OBO BETTERMANN
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲| Bend protection | no |
|---|---|
| CO2 Footprint (GWP) Cradle-to-Gate | 0,0783 kg CO2e / 1 Piece |
| Colour | Pastel orange; RAL 2003 |
| Dimension | M25 |
| Dimension E | 32 mm |
| Dimension E1 (mm) | 32 mm |
| Dimension E2 | 36 mm |
| Dimension G | M25 x 1,5 mm |
| Dimension L max. | 35 mm |
| Dimension L min. | 26 mm |
| Dimension L1 | 10 mm |
| Dimension L2 | 6 mm |
| Dimension L3 | 6,5 mm |
| Fibre-glass reinforced | no |
| Flame-resistant | acc. to VDE 0471/DIN 695 Part 2-1, test temperature 650°C |
| Flat cable gland | no |
| For Ex zone | Without |
| For Ex zone dust | Without |
| For Ex zone gas | Without |
| Halogen-free | yes |
| Impact-resistant | no |
|---|---|
| Material | Polyamide |
| Permitted temperature range, max. | 65 °C |
| Permitted temperature range, min. | -20 °C |
| Protection rating | IP68 |
| Sealing area D, max. | 17 mm |
| Sealing area D, min. | 9 mm |
| Sealing insert, multiple | no |
| Splittable gland | no |
| Strain relief option | yes |
| Thread | M25 x 1,5 |
| Thread increase | 1,5 mm |
| Thread length | 10 mm |
| Thread type | Metric |
| Unstable torque | 5 Nm |
| WAF | 29 |
| WAF 1 | 29 mm |
| WAF 2 | 32 mm |
| With locknut | yes |
