OBO BETTERMANN FBA-B200-14 FBA-B200-14 7202505 OBO BETTERMANN BLOCK FOAM FBA-B200-14 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

FBA-B200-14 7202505 OBO BETTERMANN BLOCK FOAM FBA-B200-14

FBA-B200-14

7202505

OBO BETTERMANN

4 Pcs.

BLOCK FOAM FBA-B200-14 FBA-B200-14 foam block, Intumescent 200x144x60mm Permanently elastic spongy material, closed porosity, PYROPLUG® Block foam block. Permanently elastic soft foam block for cable and combination insulation. Possibility of longitudinal and transverse mounting to achieve different fire resistance classes. Can be combined with the 2-component PYROSIT® NG firefighting foam. Usable on solid ceilings and walls and on lightweight partition walls, and approved for many installations. Indoor use. CE marked construction product, with European approval according to ETA-15/0803 for applications with a fuge-resistant duration of up to 120 minutes. More detailed information about the applications can be found in the authorization documents. Protect the surface of the insulation against water with spongy materials to ensure proper expansion of the foam in the event of a fire. Conventional silicone coating

Automation > Fire partitioning
BSS fire protection systems - OBO BETTERMANN

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Obo Bettermann block foam, part number FBA-B200-14 7202505, engineered for modular passive fire protection systems.

Intumescent foam blocks are widely utilized in building construction to seal cable penetrations, expanding during a fire to block flames and toxic gases. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Model (EF000010): Foam blocks
  • Shape (EF000051): Quadrangular
  • Outer height (EF008489): 60 mm
  • Outer width (EF008488): 144 mm
  • Plate thickness/product length (EF008015): 200 mm
  • Accessories required (EF008141): Yes

More info

▲
Foam block for cable and combination insulation, can also be used as a filler block in the PYROSIT® NG fire protection foam system.
The blocks must be protected against water in order to guarantee safe expansion in the case of fire.
