MURRELEKTRONIK 44331 44331 MURRELEKTRONIK MIRO TEMP. CONVERTER PT100 2/3-LEAD METHOD View larger
Images are for illustrative purposes only. Please refer to data sheet for details

44331 MURRELEKTRONIK MIRO TEMP. CONVERTER PT100 2/3-LEAD METHOD

44331

44331

MURRELEKTRONIK

1 unit


Automation > Relays, converters, switches
Relays, converters, switches

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Murrelektronik 44331 miro temp. converter pt100 2/3-lead method converts thermal inputs from Pt100 sensors into reliable analog control signals. Industrial temperature transducers ensure accurate data acquisition in automation networks.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Operating voltage: 24 V DC (18...30 V DC), smoothed
  • Operating current: max. 80 mA
  • Cable resistance (without Pt100): max. 100 Ω (3-wire technology)
  • Output signals at 0...10 V DC: max. 25 mA, overload protected
  • Output signals at 0...20 mA: max. 500 Ω RL
  • Output signals at 4...20 V mA: max. 500 Ω RL
  • Tolerance: ±1% from end value
  • Dimensions H×W×D: 90×12.4×70 mm
  • Mounting method: DIN-rail mountable (EN 60715)
  • Temperature range: 0...+60 °C
  • country of origin: CZ
  • customs tariff number: 85437090
  • EAN: 4048879028257
  • eClass: 27210990
  • Packaging unit: 1

More info

▲
INPUT: -50...+150 °C
Screw terminals
Technical Data
Operating voltage24 V DC (18...30 V DC), smoothed
Operating currentmax. 80 mA
Cable resistance (without Pt100)max. 100 Ω (3-wire technology)
Output signals at 0...10 V DCmax. 25 mA, overload protected
Output signals at 0...20 mAmax. 500 Ω RL
Output signals at 4...20 V mAmax. 500 Ω RL
Tolerance±1% from end value
General data
Dimensions H×W×D90×12.4×70 mm
Mounting methodDIN-rail mountable (EN 60715)
Temperature range0...+60 °C
Description
Functional descriptionThe Murrelektronik temperature converter module works in conjunction with a temperature sensor PT100 (IEC 751/EN 60751) and converts the temperature into a standard signal format of (0...10 V, 4...20 mA, 0...20 mA). The MTW modules supply a constant curre
Commercial data
country of originCZ
customs tariff number85437090
EAN4048879028257
eClass27210990
Packaging unit1
