MURRELEKTRONIK 44233 44233 MURRELEKTRONIK MUIW ANALOG COUPLER COMPONENT View larger
Images are for illustrative purposes only. Please refer to data sheet for details

44233 MURRELEKTRONIK MUIW ANALOG COUPLER COMPONENT

44233

44233

MURRELEKTRONIK

1 unit


Automation > Relays, converters, switches
Relays, converters, switches

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲
IN: 0..10 V - OUT: 4..20 mA
Art.No.: 44233
Alternative product: Product Comparison
INPUT: 0...10 V DC
OUTPUT: 4...20 mA
Screw terminals
Input and output galvanically separated
Technical Data
Operating voltage24 V DC ±20%, smoothed
Operating current50...70 mA
Tolerancemax. 0.5%
Frequencymax. 500 Hz
General data
Test isolation voltage1.5 kV
Mounting methodDIN-rail mountable (EN 60715)
Temperature range0...+60 °C
Dimensions H × W × D91×6.2×70 mm
Voltage inputs
Input resistorapprox. 200 kΩ
Voltage output signals
Loadmax. 25 mA
Current outputs
Loadmax. 500 Ω
Description
Functional descriptionThe Murrelektronik analog converters convert standard signal formats (0...10 V, 0...20 mA, 4...20 mA) galvanically separated into one of these signal formats. Due to an integrated current limiter the output is short-circuit and overload protected. Module
Commercial data
country of originCZ
customs tariff number85437090
EAN4048879028394
eClass27210990
Packaging unit1
