MURRELEKTRONIK 44232 44232 MURRELEKTRONIK MUIW ANALOG COUPLER COMPONENT View larger
Images are for illustrative purposes only. Please refer to data sheet for details

44232 MURRELEKTRONIK MUIW ANALOG COUPLER COMPONENT

44232

44232

MURRELEKTRONIK

1 unit


Automation > Relays, converters, switches
Relays, converters, switches

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

This Murrelektronik MUIW analog coupler component functions as an interfacing element designed to bridge analog signal loops within decentralized industrial control layouts. These units help maintain accurate data transmission and galvanic isolation between sensors and processing units. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Art.No.:: 44232

More info

▲
IN: 0..10 V - OUT: 0..20 mA
Art.No.: 44232
Alternative product: Product Comparison
INPUT: 0...10 V DC
OUTPUT: 0...20 mA
Screw terminals
Input and output galvanically separated
Technical Data
Operating voltage24 V DC ±20%, smoothed
Operating current50...70 mA
Tolerancemax. 0.5%
Frequencymax. 500 Hz
General data
Test isolation voltage1.5 kV
Mounting methodDIN-rail mountable (EN 60715)
Temperature range0...+60 °C
Dimensions H × W × D91×6.2×70 mm
Voltage inputs
Input resistorapprox. 250 kΩ
Voltage output signals
Loadmax. 25 mA
Current outputs
Loadmax. 500 Ω
Description
Functional descriptionThe Murrelektronik analog converters convert standard signal formats (0...10 V, 0...20 mA, 4...20 mA) galvanically separated into one of these signal formats. Due to an integrated current limiter the output is short-circuit and overload protected. Module
Commercial data
country of originCZ
customs tariff number85437090
EAN4048879028400
eClass27210990
Packaging unit1
