MURRELEKTRONIK 44226 44226 MURRELEKTRONIK MIIW ANALOG COUPLER COMPONENT View larger
Images are for illustrative purposes only. Please refer to data sheet for details

44226 MURRELEKTRONIK MIIW ANALOG COUPLER COMPONENT

44226

44226

MURRELEKTRONIK

1 unit


Automation > Relays, converters, switches
Relays, converters, switches

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

The Murrelektronik MIIW analog coupler component acts as an essential interface device for managing and isolating analog instrumentation signals in automated industrial environments. Such couplers support reliable communication between measuring instruments and control architecture. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Art.No.:: 44226

More info

▲
IN: 0(4)..20 mA - OUT: 0(4)..20 mA
Art.No.: 44226
Alternative product: Product Comparison
INPUT: 0...20 mA
OUTPUT: 0...20 mA
Screw terminals
Input and output galvanically separated
Technical Data
Operating voltage24 V DC ±20%, smoothed
Operating current50...70 mA
Tolerancemax. 0.5%
Frequencymax. 500 Hz
General data
Test isolation voltage1.5 kV
Mounting methodDIN-rail mountable (EN 60715)
Temperature range-25...+50 °C (storage temperature -40...+80 °C)
Dimensions H × W × D91×6.2×70 mm
Current input signals
Loadapprox. 250 Ω
Voltage output signals
Loadmax. 25 mA
Current outputs
Loadmax. 500 Ω
Description
Functional descriptionThe Murrelektronik analog converters convert standard signal formats (0...10 V, 0...20 mA, 4...20 mA) galvanically separated into one of these signal formats. Due to an integrated current limiter the output is short-circuit and overload protected. Module
Commercial data
country of originCZ
customs tariff number85437090
EAN4048879028431
eClass27210990
Packaging unit1
