MURRELEKTRONIK 44207 44207 MURRELEKTRONIK MMW ANALOG COUPLER COMPONENT View larger
Images are for illustrative purposes only. Please refer to data sheet for details

44207 MURRELEKTRONIK MMW ANALOG COUPLER COMPONENT

44207

44207

MURRELEKTRONIK

1 unit


Automation > Relays, converters, switches
Relays, converters, switches

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Murrelektronik 44207 mmw analog coupler component isolates and transmits analog process signals safely between disparate control loops. Analog isolators prevent ground loops and electrical interference in automation networks.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Dimensions H×W×D: 90×12.4×70 mm
  • Test isolation voltage: 0.75 kV
  • Mounting method: DIN-rail mountable (EN 60715)
  • Temperature range: -25...+50 °C
  • Input voltage: 0...5, 0...10, ±10 V DC
  • Input resistor: approx. 100 kΩ
  • Input current: 0...20 mA, 4...20 mA
  • Load: approx. 75 Ω
  • Load: max. 400 Ω
  • country of origin: CZ
  • customs tariff number: 85437090
  • EAN: 4048879028479
  • eClass: 27210990
  • Packaging unit: 1

More info

▲
INPUT: 0...5 V DC, 0...10 V DC, ±10 V DC
INPUT: 0...20 mA, 4...20 mA
Screw terminals
Input, output, and supply voltage galvanically separated
General data
Dimensions H×W×D90×12.4×70 mm
Test isolation voltage0.75 kV
Mounting methodDIN-rail mountable (EN 60715)
Temperature range-25...+50 °C
Description
Functional descriptionDue to an integrated current limiter on the output, the output is short circuit and overload protected. A special characteristic of the MULTI Converter Art.-No. 6644207 includes: Analog voltage signals 0...5 V/0...10 V and -10…+10 V and current signals 0.
Voltage inputs
Input voltage0...5, 0...10, ±10 V DC
Input resistorapprox. 100 kΩ
Current input signals
Input current0...20 mA, 4...20 mA
Loadapprox. 75 Ω
Current outputs
Loadmax. 400 Ω
Commercial data
country of originCZ
customs tariff number85437090
EAN4048879028479
eClass27210990
Packaging unit1

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
