MURRELEKTRONIK 44110 44110 MURRELEKTRONIK MAK VOLTAGE COMPARATOR MODULE View larger
Images are for illustrative purposes only. Please refer to data sheet for details

44110 MURRELEKTRONIK MAK VOLTAGE COMPARATOR MODULE

44110

44110

MURRELEKTRONIK

1 unit


Automation > Relays, converters, switches
Relays, converters, switches

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Murrelektronik part number 44110 is a voltage comparator module engineered to monitor electrical levels and trigger switching actions when preset thresholds are reached. These modules provide precise signal evaluation for automated process control and error detection. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Operating voltage: 20...30 V DC, smoothed
  • Operating current: 30 mA (idle load), max. 0.8 A (full load)
  • Time constant: approx. 10 ms
  • Input hysteresis: max. 0.5% from end value, max. 150 mV
  • Mounting method: DIN-rail mountable (EN 60715)
  • Temperature range: 0...+50 °C
  • Dimensions H×W×D: 90×12.4×70 mm
  • Number: 3 transistor outputs
  • Output current: max. 0.7 A (per channel), short-circuit protected (pulse switching)
  • Input voltage: 2× 0...30 V DC (IN 1, IN 2)
  • Input resistor: 100 kΩ
  • country of origin: CZ
  • customs tariff number: 85437090
  • EAN: 4048879028547
  • eClass: 27210990
  • Packaging unit: 1

More info

▲
2× 0...30 V DC (IN 1, IN 2)
Screw terminals
with bridge system
Technical Data
Operating voltage20...30 V DC, smoothed
Operating current30 mA (idle load), max. 0.8 A (full load)
Time constantapprox. 10 ms
Input hysteresismax. 0.5% from end value, max. 150 mV
General data
Mounting methodDIN-rail mountable (EN 60715)
Temperature range0...+50 °C
Dimensions H×W×D90×12.4×70 mm
Output
Number3 transistor outputs
Output currentmax. 0.7 A (per channel), short-circuit protected (pulse switching)
Input
Input voltage2× 0...30 V DC (IN 1, IN 2)
Input resistor100 kΩ
Description
Functional descriptionThe DC- or AC-voltage comparator serves for evaluating analog voltages, generated by pressure, temperature or other sensors. The analog input values are compared to internal or external reference voltages to over or underflow. Outputs will be switched, de
Commercial data
country of originCZ
customs tariff number85437090
EAN4048879028547
eClass27210990
Packaging unit1
