View larger
Images are for illustrative purposes only. Please refer to data sheet for details
10701 MURRELEKTRONIK EMPARRO MEF 1/1 1-phase, 1-stage
10701
10701
MURRELEKTRONIK
1 unit
Automation > EMC filters and ground meshes
EMC filters and ground meshes
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲I:20A U:230 VAC, snap on, with surge protection
| Art.No.: | 10701 |
| Weight: | 0.42 kg |
Over voltage protection
Current: 20 A
DIN-rail mountable
Attenuation curves on request.
Current: 20 A
DIN-rail mountable
Attenuation curves on request.
Technical Data
| Operating voltage | 85...265 V AC/100...230 V DC |
|---|---|
| Operating frequency | 50...60 Hz |
| Consumption | max. 1 mA (250 V AC) |
| Connection cross section | 1.5...10 mm² single core (AWG 16...8); 1.5...6 mm² multiple core (AWG 16...10) |
General data
| Climatic category | Environment class (EN 60721) |
|---|---|
| Connection | Push-In terminals |
| Mounting method | DIN-rail mountable TH35 (EN 60715) |
| Dimensions H × W × D | 123×50×138 mm |
Commercial data
| country of origin | RO |
|---|---|
| customs tariff number | 85363030 |
| EAN | 4048879464468 |
| eClass | 27130806 |
| Packaging unit | 1 |
