EPP-500-54 MEANWELL AC-DC Single output Open frame power supply with PFC, Output 54VDC / 9.26A
EPP-500-54
EPP-500-54
MEANWELL
1 unit
Automation > OPEN FRAME
EPP
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Details
Power supply in an open format(open-Frame)with PFC.
Range of universal Input80-264vac47-63Hz.
Output voltage24vdc.Adjustable by potentiometer (51-57cc).
Output intensity5,93 without fanand9,26 with fanexternal of 25 CFM.
Power:320,2 Wwithout fanand500W with fanexternal.
Efficiency typical:94%.
Can be used as a source ofclass IIwithout the taking of land with EMC EN55032classor as a source ofclass Iwith functional earth and EMC EN55032class B.
Factor corrector, power>0,94to 230vac at full load.
Alarm output voltage correct (DC-Ok).
Remote on / off.
Auxiliary output Stand-by 5V 0.6 A (1A with external fan) and a 12V 0.5 A for the fan.
Function of sensing to compensate the voltage drop in the cables.
Led indicator of operation.
Operating temperature range from-30up+70ºC.Consult the technical data sheet to see the curves of drift.
Meets class B EMI, Electromagnetic Immunity, both systems of class I (with ground) class II (without grounding).
Dimensions (Length x Width x Height) [mm]:127 x 76.2 x 43.
3 years of warranty.
Manufacturer: MEAN WELL.
The series EPP-500 are power sources in a compact size of 5" x 3", high efficiency, low consumption without load (with the remote shutdown <0.5 W) and low noise and ripple. Designed for industrial applications, automation, control systems, mechanical equipment, and electro-mechanical, instrumentation, and telecommunications equipment.
Additional information
| Name | PPE-500-54 |
|---|---|
| Long Description | Power supply in an open format(open-Frame)with PFC. Range of universal Input80-264vac47-63Hz. Output voltage24vdc.Adjustable by potentiometer (51-57cc). Output intensity5,93 without fanand9,26 with fanexternal of 25 CFM. Power:320,2 Wwithout fanand500W with fanexternal. Efficiency typical:94%. Can be used as a source ofclass IIwithout the taking of land with EMC EN55032classor as a source ofclass Iwith functional earth and EMC EN55032class B. Factor corrector, power>0,94to 230vac at full load. Alarm output voltage correct (DC-Ok). Remote on / off. Auxiliary output Stand-by 5V 0.6 A (1A with external fan) and a 12V 0.5 A for the fan. Function of sensing to compensate the voltage drop in the cables. Led indicator of operation. Operating temperature range from-30up+70ºC.Consult the technical data sheet to see the curves of drift. Meets class B EMI, Electromagnetic Immunity, both systems of class I (with ground) class II (without grounding). Dimensions (Length x Width x Height) [mm]:127 x 76.2 x 43. 3 years of warranty. Manufacturer: MEAN WELL. The series EPP-500 are power sources in a compact size of 5" x 3", high efficiency, low consumption without load (with the remote shutdown <0.5 W) and low noise and ripple. Designed for industrial applications, automation, control systems, mechanical equipment, and electro-mechanical, instrumentation, and telecommunications equipment. |
| Country of Origin | China |
| Manufacturer | MEAN WELL |
| Product type | Power supply AC/DC |
| Format | Open Format |
| Subformato | 5"x3" |
| Applications | Automotive, Industrial, Instrumentation, Telecommunications |
| Series | PPE-500 |
| State | Recommended Model |
| Warranty (Years) | 3,00 |
| Height (mm) | 43.00 |
| Width (mm) | 76.20 |
| Long/Background | 127.00 |
| Type of Entry CA | Single-phase |
| AC input Min | 80,00 |
| AC input Max | 264,00 |
| Input frequency | 50 Hz, 60 Hz |
| Input connector | Plug-in |
| Output voltage | 54,00 |
| Power (W) | 320,20 |
| Peak Power (W) | Five hundred |
| Output connector | Screw-Type |
| Alarms | Input OK |
| Isolation (V) | 3.000,00 |
| Approvals | EC, EAC, UL |
