EPP-500-12 MEANWELL AC-DC Single output Open frame power supply with PFC, Output 12VDC / 41.6A
EPP-500-12
EPP-500-12
MEANWELL
1 unit
Automation > OPEN FRAME
EPP
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲Details
Power supply in an open format(Open-Frame)with PFC function.
Range of universal Input80-264vac47-63Hz.
Output voltage12vdc.Adjustable by potentiometer (11,4-12,6 Vdc).
Output intensity26,7 without fanand41,6 with fanexternal of 25 CFM.
Power:320,4 Wwithout fanand499,2 W with fanexternal.
Efficiency typical:91%.
Can be used as a source ofclass IIwithout the taking of land with EMC EN55032classor as a source ofclass Iwith functional earth and EMC EN55032class B.
Factor corrector, power>0,94to 230vac at full load.
Alarm output voltage correct (DC-Ok).
Remote on / off.
Auxiliary output Stand-by 5V 0.6 A (1A with external fan) and a 12V 0.5 A for the fan.
Function of sensing to compensate the voltage drop in the cables.
Led indicator of operation.
Operating temperature range from-30up+70ºC.
Meets class B EMI, Electromagnetic Immunity, both systems of class I (with ground) class II (without grounding).
Dimensions (Length x Width x Height) [mm]:127 x 76.2 x 43.
3 years of warranty.
Manufacturer: MEAN WELL.
The series EPP-500 are power sources in a compact size of 5" x 3", high efficiency, low consumption without load (with the remote shutdown <0.5 W) and low noise and ripple. Designed for industrial applications, automation, control systems, mechanical equipment, and electro-mechanical, instrumentation, and telecommunications equipment.
Additional information
| Name | PPE-500-12 |
|---|---|
| Long Description | Power supply in an open format(Open-Frame)with PFC function. Range of universal Input80-264vac47-63Hz. Output voltage12vdc.Adjustable by potentiometer (11,4-12,6 Vdc). Output intensity26,7 without fanand41,6 with fanexternal of 25 CFM. Power:320,4 Wwithout fanand499,2 W with fanexternal. Efficiency typical:91%. Can be used as a source ofclass IIwithout the taking of land with EMC EN55032classor as a source ofclass Iwith functional earth and EMC EN55032class B. Factor corrector, power>0,94to 230vac at full load. Alarm output voltage correct (DC-Ok). Remote on / off. Auxiliary output Stand-by 5V 0.6 A (1A with external fan) and a 12V 0.5 A for the fan. Function of sensing to compensate the voltage drop in the cables. Led indicator of operation. Operating temperature range from-30up+70ºC. Meets class B EMI, Electromagnetic Immunity, both systems of class I (with ground) class II (without grounding). Dimensions (Length x Width x Height) [mm]:127 x 76.2 x 43. 3 years of warranty. Manufacturer: MEAN WELL. The series EPP-500 are power sources in a compact size of 5" x 3", high efficiency, low consumption without load (with the remote shutdown <0.5 W) and low noise and ripple. Designed for industrial applications, automation, control systems, mechanical equipment, and electro-mechanical, instrumentation, and telecommunications equipment. |
| Country of Origin | China |
| Manufacturer | MEAN WELL |
| Product type | Power supply AC/DC |
| Format | Open Format |
| Subformato | 5"x3" |
| Applications | Automotive, Industrial, Instrumentation, Telecommunications |
| Series | PPE-500 |
| State | Recommended Model |
| Warranty (Years) | 3,00 |
| Height (mm) | Forty three |
| Width (mm) | 76.2 |
| Long/Background | One hundred twenty seven |
| Type of Entry CA | Single-phase |
| AC input Min | 80,00 |
| AC input Max | 264,00 |
| Input frequency | 50 Hz, 60 Hz |
| Input connector | Plug-in |
| Output voltage | 12,00 |
| Power (W) | 320,40 |
| Peak Power (W) | 499.2 |
| Output connector | Screw-Type |
| Alarms | Output OK |
| Isolation (V) | 3.000,00 |
| Approvals | EC, EAC, UL |
