RSP-3000-48 MEANWELL AC-DC Single Output Enclosed power supply, Output 48VDC Single Output / 62.5A, PFC, for..
RSP-3000-48
RSP-3000-48
MEANWELL
1 unit
Automation > PFC
RSP
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲| Name | RSP-3000-48 |
|---|---|
| Long Description | Switch mode power supply. Format in box. Range of universal Input180-264vac47-63Hz. Output voltage48vdc. Adjustable by potentiometer (43-56Vcc). Output intensity62,5 To. Current range of output 0-62,5 according To the demand load. Factor Corrector, Power>0,95. Power:3000W. Efficiency typical:91,5%. Paralelizable up to 4 units. Output voltage manual. Working temperature: from-20up+70 ° Cof ambient temperature. Consult the technical data sheet to see the curves of drift. Dimensions (Length x Width x Height) [mm]:278 x 177,8 x 63.5. 5 years of warranty. Manufacturer: MEAN WELL The series RSP are sources switched low profile (63.5 mm or 1U) with correction factor power active. Include possibility of performing a power on/off remote and a LED power indicator. |
| Country of Origin | Taiwan |
| Stock | Yes |
| Manufacturer | MEAN WELL |
| Product type | Power supply AC/DC |
| Format | Box |
| Applications | Industrial, Telecommunications |
| Series | RSP-3000 |
| State | Recommended Model |
| Warranty (Years) | 5,00 |
| Height (mm) | 63.50 |
| Width (mm) | 177.80 |
| Long/Background | 278.00 |
| Type of Entry CA | Single-phase |
| AC input Min | 180,00 |
| AC input Max | 264,00 |
| Input frequency | 50 Hz, 60 Hz |
| Input connector | Screw-Type |
| Output voltage | 48,00 |
| Power (W) | 3.000,00 |
| Peak Power (W) | Three thousand |
| Output connector | Screw-Type |
| Fan | Yes |
| Alarms | Output OK |
| Isolation (V) | 3.000,00 |
| Approvals | CE, UL |
