SM1RT2300 LOVATO Transformer Protection 17-23A
SM1RT2300
SM1RT2300
LOVATO ELECTRIC
1 Pcs.
Transformer Protection 17-23A
Motor protection circuit breaker, transformer protection, IEC breaking capacity Icu 50kA at 400V, 17...23A
Automation > Motor protection circuit-breaker
Motor protection circuit breakers - LOVATO ELECTRIC
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲SM1RT2300
Motor protection circuit breaker, transformer protection, IEC breaking capacity Icu 50kA at 400V, 17...23A
Technical specifications
- Type of product:
- Motor protection circuit breaker
- Thermal trip adjustment range [A]:
- 17…23
- Rated current In [A]:
- 23
- Short-circuit current breaking capacity (Icu) at AC 400V [kA]:
- 50
- Type of protection:
- Magnetic and thermal
- Type of control:
- Rotary knob
- Certified UL Type E:
- No
| Order code | SM1RT2300 |
|---|---|
| Weight [g] | 340 |
| Qty. per package | 1 |
| Multiple qty. of packs per order | 1 |
| Package dimensions [mm] | 090X047X086 |
| Volume [cm³] | 363.78 |
| Bar code [EAN13] | 8013975311806 |
| HS Code | 85362010 |
| Feature Name | Feature Value |
|---|---|
| Overload release current setting (EF002336) | 17 A |
| Rated operating voltage (EF001435) | 0 V |
| Rated short-circuit breaking capacity Icu at 400 V, AC (EF007049) | 15 kA |
| Number of poles (EF001391) | 3 |
| Rated permanent current Iu (EF001389) | 23 A |
| Depth (EF000049) | 91 mm |
| Height (EF000040) | 97 mm |
| Width (EF000008) | 45 mm |
| Phase failure sensitive (EF007400) | Yes |
| With thermal overload protection (EF006233) | Yes |
| With integrated under voltage release (EF001390) | No |
| With integrated auxiliary switch (EF001387) | No |
| Device construction (EF008240) | Complete device in housing |
| Switch off technique (EF007007) | Thermomagnetic |
| Type of control element (EF006976) | Rotating button |
| Type of electrical connection of main circuit (EF006819) | Screw connection |
| Degree of protection (IP) (EF005474) | IP20 |
