LOVATO ELECTRIC SM1RT1800 SM1RT1800 LOVATO 13-18A Transformer Protection View larger
Images are for illustrative purposes only. Please refer to data sheet for details

SM1RT1800 LOVATO 13-18A Transformer Protection

SM1RT1800

SM1RT1800

LOVATO ELECTRIC

1 Pcs.

13-18A Transformer Protection Motor protection circuit breaker, transformer protection, IEC breaking capacity Icu 100kA at 400V, 13...18A

Automation > Motor protection circuit-breaker
Motor protection circuit breakers - LOVATO ELECTRIC

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

A Lovato Electric transformer protection unit (SM1RT1800) is specifically designed to safeguard dry-type and oil-immersed transformers against excessive current loads and internal faults. These specialized devices are frequently integrated into electrical substation panels to ensure reliable power conversion and asset protection. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Overload release current setting (EF002336): 13 A
  • Rated operating voltage (EF001435): 0 V
  • Number of poles (EF001391): 3
  • Rated permanent current Iu (EF001389): 18 A
  • Depth (EF000049): 91 mm
  • Height (EF000040): 97 mm
  • Width (EF000008): 45 mm
  • Phase failure sensitive (EF007400): Yes
  • With thermal overload protection (EF006233): Yes
  • With integrated under voltage release (EF001390): No
  • With integrated auxiliary switch (EF001387): No
  • Device construction (EF008240): Complete device in housing
  • Switch off technique (EF007007): Thermomagnetic
  • Type of control element (EF006976): Rotating button
  • Type of electrical connection of main circuit (EF006819): Screw connection
  • Degree of protection (IP) (EF005474): IP20

More info

▲

SM1RT1800

Motor protection circuit breaker, transformer protection, IEC breaking capacity Icu 100kA at 400V, 13...18A

Technical specifications

Type of product:
Motor protection circuit breaker
Thermal trip adjustment range [A]:
13…18
Rated current In [A]:
18
Short-circuit current breaking capacity (Icu) at AC 400V [kA]:
100
Type of protection:
Magnetic and thermal
Type of control:
Rotary knob
Certified UL Type E:
No
Order codeSM1RT1800
Weight [g]340
Qty. per package1
Multiple qty. of packs per order1
Package dimensions [mm]090X047X086
Volume [cm³]363.78
Bar code [EAN13]8013975311790
HS Code85362010
