SM1RT0016 LOVATO Transformer Protection 0.1-0.16A
SM1RT0016
SM1RT0016
LOVATO ELECTRIC
1 Pcs.
Automation > Motor protection circuit-breaker
Motor protection circuit breakers - LOVATO ELECTRIC
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
A Lovato Electric SM1RT0016 transformer protection device is designed to secure specialty electrical transformers against excessive overloads and short circuits in industrial automation setups.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Overload release current setting (EF002336): 0.1 A
- Rated operating voltage (EF001435): 0 V
- Number of poles (EF001391): 3
- Rated permanent current Iu (EF001389): 0.16 A
- Depth (EF000049): 91 mm
- Height (EF000040): 97 mm
- Width (EF000008): 45 mm
- Phase failure sensitive (EF007400): Yes
- With thermal overload protection (EF006233): Yes
- With integrated under voltage release (EF001390): No
- With integrated auxiliary switch (EF001387): No
- Device construction (EF008240): Complete device in housing
- Switch off technique (EF007007): Thermomagnetic
- Type of control element (EF006976): Rotating button
- Type of electrical connection of main circuit (EF006819): Screw connection
- Degree of protection (IP) (EF005474): IP20
More info
▲SM1RT0016
Motor protection circuit breaker, transformer protection, IEC breaking capacity Icu 100kA at 400V, 0.1...0.16A
Technical specifications
- Type of product:
- Motor protection circuit breaker
- Thermal trip adjustment range [A]:
- 0.1…0.16
- Rated current In [A]:
- 0.16
- Short-circuit current breaking capacity (Icu) at AC 400V [kA]:
- 100
- Type of protection:
- Magnetic and thermal
- Type of control:
- Rotary knob
- Certified UL Type E:
- No
| Order code | SM1RT0016 |
|---|---|
| Weight [g] | 340 |
| Qty. per package | 1 |
| Multiple qty. of packs per order | 1 |
| Package dimensions [mm] | 090X047X086 |
| Volume [cm³] | 363.78 |
| Bar code [EAN13] | 8013975311684 |
| HS Code | 85362010 |
