LOVATO ELECTRIC RFN200100 RFN200100 LOVATO MOTOR PROTECTION RELAY, NON PHASE FAILURE / NON SINGLE PHASE SENSITIVE. THREE POLE (THREE P.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

RFN200100 LOVATO MOTOR PROTECTION RELAY, NON PHASE FAILURE / NON SINGLE PHASE SENSITIVE. THREE POLE (THREE P..

RFN200100

200100

LOVATO ELECTRIC

1 Pcs.

MOTOR PROTECTION RELAY, NON PHASE FAILURE / NON SINGLE PHASE SENSITIVE. THREE POLE (THREE PHASE), MANUAL OR AUTOMATIC RESETTING, 60…100A T/O RELAY 60-100A MAN-AUTO Motor protection relay, non phase failure/non single-phase sensitive. Three-pole (three-phase), manual or automatic resetting, 60...100A MOTOR PROTECTION RELAY, NOT PHASE FAULT SENSITIVE, MANUAL OR AUTOMATIC RESET, 60...100A

Automation > Thermal overload relay
Motor protection relays - LOVATO ELECTRIC

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Add your required quantity to begin.

No account, online checkout or payment is required.

More info

▲

RFN200100

Motor protection relay, non phase failure/non single-phase sensitive. Three-pole (three-phase), manual or automatic resetting, 60...100A

Technical specifications

Type of product:
Thermal overload relays
Operational current [A]:
60...100
Reset mode:
Manual or automatic
For contactor series:
B
Type:
Non phase failure / Non single-phase sensitive
Type of mounting:
Screw
Order codeRFN200100
Weight [g]2140
Qty. per package1
Multiple qty. of packs per order1
Package dimensions [mm]135X130X175
Volume [cm³]3071.25
Bar code [EAN13]8013975168981
HS Code85364900

425.32 £


ETIM for RFN200100 Low-voltage industrial controls and switchgear (EC000106)
Feature Name Feature Value
Type of electrical connection of main circuit (EF006819) Screw connection
Release class (EF006668) CLASS 10 A
Mounting method (EF000003) Direct attachment/single positioning
Adjustable current range (EF008211) 60 A
Reset function push-button (EF011942) Yes
Reset function automatic (EF011941) Yes
Reset function input (EF011940) No
Max. rated operation voltage Ue (EF007357) 1000 V
Number of auxiliary contacts as change-over contact (EF003531) 0
Number of auxiliary contacts as normally closed contact (EF001377) 1
Number of auxiliary contacts as normally open contact (EF001376) 1
