P1RD4P63A300S LOVATO RCCB 4P 63A IDN 300MA SELECTIVE
P1RD4P63A300S
P1RD4P63A300S
LOVATO ELECTRIC
1 Pcs.
Automation > Residual current circuit breaker (RCCB)
Miniature and residual circuit breakers
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Lovato Electric P1RD4P63A300S residual current circuit breaker is designed to protect industrial and commercial electrical assets by detecting residual operating currents and interrupting fault paths. These safety units prevent catastrophic equipment failure and reduce shock risks in complex power networks.
Pricing, availability, and lead time are confirmed per enquiry through an RFQ.
- Frequency (EF005455): 50/60 Hz
- Degree of protection (IP) (EF005474): IP20
- Leakage current type (EF002560): A
- Voltage type (EF000187): AC
- Mounting method (EF000003): DIN rail
- Ambient temperature during operating (EF007515): -25 °C
- Connectable conductor cross section solid-core (EF007337): 2.5 mm²
- Additional equipment possible (EF008148): Yes
- With interlocking device (EF007385): No
- Explosion-proof (EF004663): No
- Short-time delayed tripping (EF003604): No
- Selective protection (EF002561): Yes
- Rated impulse withstand voltage Uimp (EF011980): 4 kV
- Width in number of modular spacings (EF002950): 4
- Pollution degree (EF002570): 2
- Short-circuit breaking capacity (Icw) (EF002562): 10 kA
More info
▲P1RD4P63A300S
Residual current operated circuit breaker - selective, 4 modules, 4P - type A, 63A, 300mA
Technical specifications
- Type of product:
- Residual current operated circuit breakers
- Number of DIN modules:
- 4
- Number of poles:
- 4P
- Residual operation characteristic:
- A selective
- Rated residual current I∆n [mA]:
- 300 - selective
- Rated current In [A]:
- 63
- Compliance:
- IEC
| Order code | P1RD4P63A300S |
|---|---|
| Weight [g] | 326 |
| Qty. per package | 1 |
| Multiple qty. of packs per order | 1 |
| Package dimensions [mm] | 115X076X078 |
| Volume [cm³] | 681.72 |
| Bar code [EAN13] | 8013975312933 |
| HS Code | 85362010 |
