LOVATO ELECTRIC 11BGF09T4D125 11BGF09T4D125 BGF09T4D125 LOVATO FOUR-POLE CONTACTOR, DC COIL, 125VDC, FASTON TERMINALS View larger
Images are for illustrative purposes only. Please refer to data sheet for details

11BGF09T4D125 BGF09T4D125 LOVATO FOUR-POLE CONTACTOR, DC COIL, 125VDC, FASTON TERMINALS

11BGF09T4D125

BGF09T4D125

LOVATO ELECTRIC

1 Pcs.

FOUR-POLE CONTACTOR, DC COIL, 125VDC, FASTON TERMINALS Minicont. 4P 20A AC1 125V DC Faston Four-pole contactor, DC coil, 125VDC, Faston terminals

Automation > Power contactor, AC switching
Industrial Contactors and Accessories - LOVATO ELECTRIC

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Lovato Electric 11BGF09T4D125 four-pole contactor is engineered for switching multi-phase electrical networks and complex automation circuits. These devices are standard in control panels for managing loads such as heating elements, power supplies, and auxiliary distribution systems.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Voltage type for actuating (EF008242): DC
  • Type of electrical connection of main circuit (EF006819): Flat plug-in connection
  • Rated control supply voltage DC (EF003980): 125 V
  • Modular version (EF001126): No
  • Rated operation current Ie at AC-4, 400 V (EF008495): 4 A
  • Rated operation current Ie at AC-1, 400 V (EF001393): 20 A
  • Rated operation current Ie at AC-3, 400 V (EF001392): 9 A
  • Number of normally open contacts as main contact (EF001374): 4
  • Rated operation power at AC-3, 400 V (EF001364): 4 kW

More info

▲

11BGF09T4D125

Four-pole contactor, DC coil, 125VDC, Faston terminals

Technical specifications

Type of product:
Contactors
Number of poles:
4
Type of coil:
DC coil
Rated coil voltage [V]:
125
IEC operating current Ith (AC1) [A]:
20
IEC operating current and power Ie (AC3) 400V [A/Kw]:
9A / 4.0Kw
UL/CSA horsepower ratings 480V [HP]:
5
Type of mounting:
Screw / DIN rail 35mm
Order code11BGF09T4D125
Weight [g]210
Qty. per package1
Multiple qty. of packs per order1
Package dimensions [mm]060X045X060
Volume [cm³]162
Bar code [EAN13]8013975121634
HS Code85365080

69.78 £


Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
