LOVATO ELECTRIC 11G3566 11G3566 G3566 LOVATO MECHANICAL INTERLOCK, FOR B SERIES CONTACTORS, ONE ON TOP OF OTHER View larger
Images are for illustrative purposes only. Please refer to data sheet for details

11G3566 G3566 LOVATO MECHANICAL INTERLOCK, FOR B SERIES CONTACTORS, ONE ON TOP OF OTHER

11G3566

G3566

LOVATO ELECTRIC

1 Pcs.

MECHANICAL INTERLOCK, FOR B SERIES CONTACTORS, ONE ON TOP OF OTHER Enclav. Mec. vertical B115.. B630 (470-500mm) Mechanical interlock, for B… series contactors, one on top of other

Automation > Accessories/spare parts for low-voltage switch technology
Industrial Contactors and Accessories - LOVATO ELECTRIC

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

A Lovato Electric mechanical interlock (11G3566) is designed to physically prevent two stacked contactors from closing simultaneously, safeguarding motor control circuits against phase-to-phase short circuits. This component is standard in reversing and multi-speed motor starter assemblies where reliable directional interlocking is mandatory.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Spare part (EF013237): No
  • Accessory (EF013236): Yes

More info

▲

11G3566

Mechanical interlock, for B… series contactors, one on top of other

Technical specifications

Type of product:
Accessories
Type of accessories:
Mechanical interlock
Accessories for:
11B…
Order code11G3566
Weight [g]150
Qty. per package1
Multiple qty. of packs per order1
Package dimensions [mm]250X450X020
Volume [cm³]2250
Bar code [EAN13]8013975005774
HS Code85365080

95.3 £
