M3P0651222060B7 LOVATO DOL STARTER M3P 220/60 65A
M3P0651222060B7
M3P0651222060B7
LOVATO ELECTRIC
1 Pcs.
DOL STARTER M3P 220/60 65A
Direct-on-line-starter, 45...65A (30kW at 400VAC), IP65, contactor coil voltage 220VAC 60Hz, non-metallic enclosure, with thermal overload relay, with START and STOP/RESET button
DIRECT STARTER, 45...65A (30KW AT 400V), CONTACTOR COIL VOLTAGE 220VAC 60HZ, WITH THERMAL RELAY IN IP65 INSULATED ENCLOSURE, WITH START AND STOP/RESET BUTTONS,
Automation > Motor starter/Motor starter combination
Electromechanical starters - LOVATO ELECTRIC
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲M3P0651222060B7
Direct-on-line-starter, 45...65A (30kW at 400VAC), IP65, contactor coil voltage 220VAC 60Hz, non-metallic enclosure, with thermal overload relay, with START and STOP/RESET button
Technical specifications
- Type of product:
- Direct-on-line-starters
- IEC operating current and power Ie (AC3) 400V [A/Kw]:
- 65A / 30kW
- UL/CSA horsepower ratings 480V [HP]:
- 50
- Type:
- Enclosed with thermal overload relay
- Type of coil:
- AC coil
| Order code | M3P0651222060B7 |
|---|---|
| Weight [g] | 3820 |
| Qty. per package | 1 |
| Multiple qty. of packs per order | 1 |
| Package dimensions [mm] | 295X240X225 |
| Volume [cm³] | 15930 |
| Bar code [EAN13] | 8013975218549 |
| HS Code | 85371098 |
| Feature Name | Feature Value |
|---|---|
| Degree of protection (NEMA) (EF011959) | 4X |
| Type of motor starter (EF009598) | Direct starter |
| Voltage type for actuating (EF008242) | AC |
| Type of electrical connection for auxiliary- and control current circuit (EF006979) | Screw connection |
| Type of electrical connection of main circuit (EF006819) | Screw connection |
| Release class (EF006668) | CLASS 10 A |
| Degree of protection (IP) (EF005474) | IP65 |
| Rated control supply voltage AC 60 Hz (EF003979) | 220 V |
| Rated control supply voltage AC 50 Hz (EF003978) | 220 V |
| Overload release current setting (EF002336) | 46 A |
| Temperature compensated overload protection (EF009604) | Yes |
| Supporting protocol for SafetyBUS p (EF007527) | No |
| Supporting protocol for PROFIsafe (EF007526) | No |
| Supporting protocol for PROFINET IO (EF007525) | No |
| Supporting protocol for PROFINET CBA (EF007524) | No |
| Supporting protocol for Foundation Fieldbus (EF007522) | No |
| Supporting protocol for EtherNet/IP (EF007521) | No |
| Supporting protocol for DeviceNet Safety (EF007520) | No |
| Supporting protocol for AS-Interface Safety at Work (EF007519) | No |
| With fuse (EF006693) | No |
| With short-circuit release (EF006691) | No |
| Supporting protocol for INTERBUS-Safety (EF006662) | No |
| Supporting protocol for SERCOS (EF006657) | No |
| Suitable for rail mounting (EF003972) | No |
| External reset possible (EF003426) | Yes |
| Supporting protocol for other bus systems (EF003062) | No |
| Supporting protocol for SUCONET (EF003060) | No |
| Supporting protocol for DeviceNet (EF003059) | No |
| Supporting protocol for Data-Highway (EF003058) | No |
| Supporting protocol for Modbus (EF003057) | No |
| Supporting protocol for INTERBUS (EF003054) | No |
| Supporting protocol for CAN (EF003053) | No |
| Supporting protocol for PROFIBUS (EF003052) | No |
| Supporting protocol for ASI (EF003051) | No |
| Supporting protocol for TCP/IP (EF003050) | No |
| Supporting protocol for LON (EF003017) | No |
| Suitable for emergency stop (EF001433) | No |
| With transformer (EF000278) | No |
| Rated conditional short-circuit current, type 2, 230 V (EF009606) | 50000 A |
| Rated conditional short-circuit current, type 2, 400 V (EF009605) | 50000 A |
| Ambient temperature, upper operating limit (EF009603) | 60 °C |
| Rated operation current at AC-3, 400 V (EF009602) | 65 A |
| Rated operation current Ie (EF001443) | 65 A |
| Number of auxiliary contacts as normally closed contact (EF001377) | 0 |
| Number of auxiliary contacts as normally open contact (EF001376) | 0 |
| Rated operation power at AC-3, 400 V (EF001364) | 30 kW |
| Depth (EF000049) | 187 mm |
| Height (EF000040) | 280 mm |
| Width (EF000008) | 233 mm |
| Number of indicator lights (EF001965) | 0 |
