LOVATO ELECTRIC P1MB1PC16 P1MB1PC16 LOVATO MINIATURE CIRCUIT BREAKER, 1P 10KA. 1 MODULE, CHARACTERISTIC C, 16A View larger
Images are for illustrative purposes only. Please refer to data sheet for details

P1MB1PC16 LOVATO MINIATURE CIRCUIT BREAKER, 1P 10KA. 1 MODULE, CHARACTERISTIC C, 16A

P1MB1PC16

P1MB1PC16

LOVATO ELECTRIC

1 unit

MINIATURE CIRCUIT BREAKER, 1P - 10KA. 1 MODULE, CHARACTERISTIC C, 16A MINIATURE CIRCUIT BREAKER 1P C 16A 10KA Miniature circuit breaker, 1P - 10kA. 1 module, characteristic C, 16A

Automation > Miniature circuit breaker (MCB)
Miniature and residual circuit breakers

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

The P1MB1PC16 LOVATO MINIATURE CIRCUIT BREAKER, 1P 10KA. 1 MODULE, CHARACTERISTIC C, 16A is a Lovato Electric miniature circuit breaker designed to automatically interrupt electrical circuits during overload or short-circuit conditions to protect downstream wiring and sensitive equipment. Circuit breakers of this type are widely deployed in commercial, residential, and industrial distribution panels for reliable branch circuit protection.

Pricing, availability, and lead time are confirmed per enquiry through an RFQ.

  • Degree of protection (IP): IP20
  • Release characteristic: C
  • Voltage type: AC/DC
  • Ambient temperature during operating: -40 °C
  • Connectable conductor cross section solid-core: 1 mm²
  • Frequency: 50 Hz
  • Additional equipment possible: Yes
  • Flush-mounted installation: No
  • Concurrently switching neutral conductor: Yes
  • Explosion-proof: No
  • Rated impulse withstand voltage Uimp: 4 kV
  • Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V: 10 kA
  • Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V: 10 kA
  • Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V: 10 kA
  • Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V: 10 kA
  • Number of poles (total): 1

More info

▲

P1MB1PC16

Miniature circuit breaker, 1P - 10kA. 1 module, characteristic C, 16A

Technical specifications

Type of product:
Miniature circuit breakers
Number of DIN modules:
1
Number of poles:
1P
Tripping curve:
C
Rated current In [A]:
16
Compliance:
IEC / UL1077
Order codeP1MB1PC16
Weight [g]115
Qty. per package12
Multiple qty. of packs per order12
Package dimensions [mm]250X100X080
Volume [cm³]166.667
Bar code [EAN13]8013975202876
HS Code85362010

18.39 £
