LOVATO ELECTRIC HS2C6HV030D024 HS2C6HV030D024 LOVATO SOLID STATE RELAY 2P 30A WITH HEAT SINK View larger
Images are for illustrative purposes only. Please refer to data sheet for details

HS2C6HV030D024 LOVATO SOLID STATE RELAY 2P 30A WITH HEAT SINK

HS2C6HV030D024

HS2C6HV030D024

LOVATO ELECTRIC

1 Pcs.

SOLID STATE RELAY 2P 30A WITH HEAT SINK Solid state relay complete with heatsink, three-phase (2 controlled), 30A, 4...32VDC, screw terminals RELE' STATO SOLIDO 2P 30A CON DISSIPATORE

Automation > Solid state relay

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

A solid state relay with heat sink, specifically the Lovato Electric HS2C6HV030D024, is engineered to switch multi-phase industrial loads while actively dissipating thermal energy to protect internal semiconductors. Panel builders utilize these complete assemblies to streamline installation in demanding thermal environments.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Voltage type for actuating (EF008242): DC
  • Rated control supply voltage DC (EF003980): 4 V
  • Rated operation current Ie at AC-53a (EF009489): 13.5 A
  • Rated operation current Ie at AC-51 (EF009488): 30 A
  • Number of phases (EF000351): 3

More info

▲

HS2C6HV030D024

Solid state relay complete with heatsink, three-phase (2 controlled), 30A, 4...32VDC, screw terminals

Technical specifications

Type of product:
Solid state relays with heatsink, three-phase
Control voltage [V]:
4...32VDC
Rated operational voltage:
48…600
Rated operating current AC-51 (resistive load) at 40°C:
30
Rated operating current AC-53 (motor load) at 40°C:
13.5
Number of poles:
2
Operating temperature max:
+80
Specific let through energy I2t:
1.4
Type of terminals:
Screw
Order codeHS2C6HV030D024
Weight [g]600
Qty. per package1
Multiple qty. of packs per order1
Package dimensions [mm]121X069X142
Volume [cm³]1185.558
Bar code [EAN13]8013975321430
HS Code85364900
