LOVATO ELECTRIC HRA101CE230S HRA101CE230S LOVATO SLIMRELAY+SOCKET SPRING 1C/O 6A 230VACDC View larger
Images are for illustrative purposes only. Please refer to data sheet for details

HRA101CE230S LOVATO SLIMRELAY+SOCKET SPRING 1C/O 6A 230VACDC

HRA101CE230S

HRA101CE230S

LOVATO ELECTRIC

1 Pcs.

SLIMRELAY+SOCKET SPRING 1C/O 6A 230VACDC Electromechanical slim relay assembled in base, 220... 240VAC/DC, 6A, 1 switched contact, spring terminals RELE' SLIM+ZOCCOLO MOLLA 1SC 6A 230VAC/DC

Automation > Switching relay
Industrial relays

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

The HRA101CE230S LOVATO SLIMRELAY+SOCKET SPRING 1C/O 6A 230VACDC functions as a compact coupling element in electrical distribution networks, providing seamless switching operations and galvanic isolation between field sensors and processing units. Slim profile relays are commonly installed where DIN rail space is limited inside control cabinets. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Rated control supply voltage DC (EF003980): 230 V
  • Rated control supply voltage AC 60 Hz (EF003979): 230 V
  • Rated control supply voltage AC 50 Hz (EF003978): 230 V
  • Number of contacts as change-over contact (EF008257): 1
  • Number of contacts as normally open contact (EF008256): 0
  • Number of contacts as normally closed contact (EF008255): 0
  • Nominal current (EF000001): 6 A
  • With LED indication (EF005950): No
  • Complete with socket (EF003359): Yes
  • With forced-guided contacts (EF003357): No
  • With detachable clamps (EF003340): No
  • Voltage type for actuating (EF008242): AC/DC
  • Degree of protection (IP) (EF005474): IP20
  • Type of electric connection (EF003961): Spring clamp connection
  • Type of switch contact (EF003358): Single contact
  • Drive, switching attitude (EF003356): Mono stable

More info

▲

HRA101CE230S

Electromechanical slim relay assembled in base, 220... 240VAC/DC, 6A, 1 switched contact, spring terminals

Technical Specifications

Product Type:
Slim relays in the socket
Type of contacts:
1 C/O
Relay Control Voltage:
220… 240VAC/VDC
IEC Conventional Outdoor Thermal Current Ith [A]:
6
Led:
Yes
Mechanical Actuator:
No
Plug Type:
Spring terminals
Order CodeHRA101CE230S
Weight [g]37
Packaging units10
Multi-pack order quantity10
Packaging dimensions [mm]365X200X210
Volume [cm³]76,65
Barcode [EAN13]8013975318713
HS Code85364900
