LOVATO ELECTRIC 7GN6355O 7GN6355O GN6355O LOVATO Selector switch "1-2" 2-pole GN55 63 TO Model Or 65x65

View larger

Images are for illustrative purposes only. Please refer to data sheet for details

7GN6355O GN6355O LOVATO Selector switch "1-2" 2-pole GN55 63 TO Model Or 65x65

Name: 7GN6355O GN6355O LOVATO Selector switch "1-2" 2-pole GN55 63 TO Model Or 65x65
Brand: LOVATO ELECTRIC
SKU: GN6355O

Reference: 7GN6355O

Code: GN6355O

Manufacturer: LOVATO ELECTRIC

Units per package: 1 Pcs.

Description:

Selector switch "1-2" 2-pole GN55 63 TO Model Or 65x65 Switch "1-2" 2 poles GN55 63 A Model O 65x65 Rotary cam switch 7GN series, changeover switch without 0, 2 poles 63A, for rear mounting with black handle, front plate 65X65mm ROTARY CAM SWITCH 7GN SERIES, CHANGEOVER SWITCH WITHOUT 0 2 POLES 63A, FOR REAR MOUNTING WITH BLACK HANDLE, FRONT PLATE 65X65MM

Categories:
Automation > Off-load switch
Rotary cam switches - LOVATO ELECTRIC

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Guarantee, repair and return.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Lovato Electric 7GN6355O selector switch is a mechanical control component designed to manually alter electrical pathways and manage power distribution across multi-pole industrial circuits. Technicians routinely integrate these versatile devices into control desks and distribution panels to govern heavy-duty motor operations and operational states.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

Type of control element (EF006976): Short thumb-grip
Type of electrical connection of main circuit (EF006819): Screw connection
Degree of protection (IP), front side (EF003118): IP40
Housing material (EF001596): Plastic
Model (EF000010): On/Off switch
Complete device in housing (EF007317): Yes
Suitable for intermediate mounting (EF007264): No
Suitable for distribution board installation (EF007262): Yes
Suitable for front mounting (EF007246): No
Suitable for floor mounting (EF007243): No
With retraction in 0-position (EF002428): No
With zero (off) position (EF001416): No
Number of poles (EF001391): 4
Rated permanent current Iu (EF001389): 63 A
Rated operation power at AC-3, 400 V (EF001364): 18.5 kW

More info

▲

7GN6355O

Rotary cam switch 7GN series, changeover switch without 0, 2 poles 63A, for rear mounting with black handle, front plate 65X65mm

Technical specifications

Type of product:: Changeover switches
Switching diagram:: 55 - Changeover switch without 0 2 poles
IEC Conventional free air thermal current Ith [A]:: 63
Mounting form:: O - Rear mounting with black handle
Series:: 7GN - round-shaped contact block

Order code	7GN6355O
Weight [g]	300
Qty. per package	1
Multiple qty. of packs per order	1
Package dimensions [mm]	067X067X130
Volume [cm³]	583.57
Bar code [EAN13]	3850144161863
HS Code	85365080

Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.

View PDF Download
