7GN2569O GN2569O LOVATO Selector switch "1-2" 4-pole GN69 25 TO Model Or 48x48
7GN2569O
GN2569O
LOVATO ELECTRIC
1 Pcs.
Automation > Off-load switch
Rotary cam switches - LOVATO ELECTRIC
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Functioning as a precise mode controller, the Lovato Electric 7GN2569O selector switch allows operators to manually switch between designated active states in electrical control loops. These modular units are standard in distribution boards and machinery consoles for supervising operating parameters. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Type of control element (EF006976): Short thumb-grip
- Type of electrical connection of main circuit (EF006819): Screw connection
- Degree of protection (IP), front side (EF003118): IP40
- Housing material (EF001596): Plastic
- Model (EF000010): On/Off switch
- Complete device in housing (EF007317): Yes
- Suitable for intermediate mounting (EF007264): No
- Suitable for distribution board installation (EF007262): Yes
- Suitable for front mounting (EF007246): No
- Suitable for floor mounting (EF007243): No
- With retraction in 0-position (EF002428): No
- With zero (off) position (EF001416): No
- Number of poles (EF001391): 8
- Rated permanent current Iu (EF001389): 25 A
- Rated operation power at AC-3, 400 V (EF001364): 7.5 kW
More info
▲7GN2569O
Rotary cam switch 7GN series, changeover switch without 0, 4 poles 25A, for rear mounting with black handle, front plate 48X48mm
Technical specifications
- Type of product:
- Changeover switches
- Switching diagram:
- 69 - Changeover switch without 0 4 poles
- IEC Conventional free air thermal current Ith [A]:
- 25
- Mounting form:
- O - Rear mounting with black handle
- Series:
- 7GN - round-shaped contact block
| Order code | 7GN2569O |
|---|---|
| Weight [g] | 173.8 |
| Qty. per package | 1 |
| Multiple qty. of packs per order | 1 |
| Package dimensions [mm] | |
| Volume [cm³] | 0 |
| Bar code [EAN13] | 3850144160859 |
| HS Code | 85365080 |
