View larger
Images are for illustrative purposes only. Please refer to data sheet for details
7GN12575O GN1255O LOVATO Selector switch "1-2" 2-pole GN55 12 TO Model Or 48x48
7GN12575O
GN1255O
LOVATO ELECTRIC
1 Pcs.
Selector switch "1-2" 2-pole GN55 12 TO Model Or 48x48
Switch "1-2" 2 poles GN55 12 A Model O 48x48
Rotary cam switch 7GN series, changeover switch 4 poles 125A, for rear mounting with black handle, front plate 90X90mm
Automation > Selector switch, complete
Rotary cam switches - LOVATO ELECTRIC
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲7GN12575O
Rotary cam switch 7GN series, changeover switch 4 poles 125A, for rear mounting with black handle, front plate 90X90mm
Technical specifications
- Type of product:
- Changeover switches
- Switching diagram:
- 75 - Changeover switch 4 poles
- IEC Conventional free air thermal current Ith [A]:
- 125
- Mounting form:
- O - Rear mounting with black handle
- Series:
- 7GN - round-shaped contact block
| Order code | 7GN12575O |
|---|---|
| Weight [g] | 1310 |
| Qty. per package | 1 |
| Multiple qty. of packs per order | 1 |
| Package dimensions [mm] | 097X097X251 |
| Volume [cm³] | 2361.659 |
| Bar code [EAN13] | 3850144008977 |
| HS Code | 85365080 |
| Feature Name | Feature Value |
|---|---|
| Type of control element (EF006976) | Short thumb-grip |
| Material front ring (EF005972) | Plastic |
| Degree of protection (IP) (EF005474) | IP40 |
| Type of electric connection (EF003961) | Screw connection |
| With front ring (EF006014) | No |
| With light source (EF005905) | No |
| Spring-return (EF001407) | No |
| Suitable for lighting (EF001142) | No |
| Number of contacts as change-over contact (EF008257) | 0 |
| Number of contacts as normally open contact (EF008256) | 4 |
| Number of contacts as normally closed contact (EF008255) | 0 |
| Number of switch positions (EF000231) | 3 |
