LOVATO ELECTRIC 11BG09T2D012 11BG09T2D012 BG09T2D012 LOVATO FOUR-POLE CONTACTOR, DC COIL, 12VDC, 2NO AND 2NC View larger
Images are for illustrative purposes only. Please refer to data sheet for details

11BG09T2D012 BG09T2D012 LOVATO FOUR-POLE CONTACTOR, DC COIL, 12VDC, 2NO AND 2NC

11BG09T2D012

BG09T2D012

LOVATO ELECTRIC

1 Pcs.

FOUR-POLE CONTACTOR, DC COIL, 12VDC, 2NO AND 2NC Minicont. 2NA+2NC 20A AC1 12V DC Four-pole contactor, DC coil, 12VDC, 2NO and 2NC

Automation > Power contactor, AC switching
Industrial Contactors and Accessories - LOVATO ELECTRIC

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Multi-pole low-voltage control circuits rely on components such as the Lovato Electric 11BG09T2D012 four-pole contactor to execute reliable automated switching tasks. It provides dependable electrical isolation and signal routing within industrial control panels. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Voltage type for actuating (EF008242): DC
  • Type of electrical connection of main circuit (EF006819): Screw connection
  • Rated control supply voltage DC (EF003980): 12 V
  • Modular version (EF001126): No
  • Rated operation current Ie at AC-1, 400 V (EF001393): 20 A
  • Rated operation current Ie at AC-3, 400 V (EF001392): 9 A
  • Number of normally open contacts as main contact (EF001374): 2

More info

▲

11BG09T2D012

Four-pole contactor, DC coil, 12VDC, 2NO and 2NC

Technical specifications

Type of product:
Contactors
Number of poles:
4
Type of coil:
DC coil
Rated coil voltage [V]:
12
IEC operating current Ith (AC1) [A]:
20
IEC operating current and power Ie (AC3) 400V [A/Kw]:
9A / 4.0Kw
UL/CSA horsepower ratings 480V [HP]:
5
Type of mounting:
Screw / DIN rail 35mm
Order code11BG09T2D012
Weight [g]221
Qty. per package1
Multiple qty. of packs per order1
Package dimensions [mm]060X045X060
Volume [cm³]162
Bar code [EAN13]8013975082768
HS Code85365080

64.49 £


Product Datasheet
