LOVATO ELECTRIC 11BG0040L048 11BG0040L048 BG0040L048 LOVATO CONTROL RELAY WITH CONTROL CIRCUIT: AC AND DC, BG00 TYPE, DC COIL LOW CONSUMP.. View larger
Images are for illustrative purposes only. Please refer to data sheet for details

11BG0040L048 BG0040L048 LOVATO CONTROL RELAY WITH CONTROL CIRCUIT: AC AND DC, BG00 TYPE, DC COIL LOW CONSUMP..

11BG0040L048

BG0040L048

LOVATO ELECTRIC

1 Pcs.

CONTROL RELAY WITH CONTROL CIRCUIT: AC AND DC, BG00 TYPE, DC COIL LOW CONSUMPTION, 48VDC, 4NO Minicont. Aux. 4P NA 10A AC1 48V dc low consumption Control relay with DC coil low consumption, 48VDC, 4NO

Automation > Contactor relay
Industrial Contactors and Accessories - LOVATO ELECTRIC

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Lovato Electric control relay (11BG0040L048) with low-consumption DC coil provides dependable switching for industrial automation and control circuits. Control relays are typically integrated into electrical panels to process logic signals and command secondary switching elements safely.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Voltage type for actuating (EF008242): DC
  • Connection type auxiliary circuit (EF006820): Screw connection
  • Mounting method (EF000003): DIN-rail/screw
  • Rated control supply voltage DC (EF003980): 48 V
  • With LED indication (EF005950): No
  • Suitable for manual operation (EF002978): No
  • Interface (EF000594): No
  • Rated operation current Ie, 400 V (EF001378): 10 A

More info

▲

11BG0040L048

Control relay with DC coil low consumption, 48VDC, 4NO

Technical specifications

Type of product:
Control relays with AC and DC control circuit
Number of poles:
4
Type of coil:
DC coil low consumption
Rated coil voltage [V]:
48
Type of built-in auxiliary contacts:
4NO
Type of mounting:
Screw / DIN rail 35mm
Order code11BG0040L048
Weight [g]206
Qty. per package1
Multiple qty. of packs per order1
Package dimensions [mm]060X045X060
Volume [cm³]162
Bar code [EAN13]8013975081204
HS Code85365080

43.49 £


Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
