BF6500A23060 LOVATO THREE-POLE CONTACTOR, IEC OPERATING CURRENT IE (AC3) 65A, AC COIL 60HZ, 230VAC
BF6500A23060
23060
LOVATO ELECTRIC
1 Pcs.
Automation > Power contactor, AC switching
Industrial Contactors and Accessories - LOVATO ELECTRIC
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
The BF6500A23060 LOVATO THREE-POLE CONTACTOR, IEC OPERATING CURRENT IE (AC3) 65A, AC COIL 60HZ, 230VAC is an industrial switching device used extensively for starting motors and managing power distribution. It allows automated systems to securely control electrical circuits through low-power command signals.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Voltage type for actuating (EF008242): AC
- Type of electrical connection of main circuit (EF006819): Frame clamp
- Rated control supply voltage AC 60 Hz (EF003979): 230 V
- Modular version (EF001126): No
- Rated operation current Ie at AC-4, 400 V (EF008495): 31 A
- Rated operation current Ie at AC-1, 400 V (EF001393): 100 A
- Rated operation current Ie at AC-3, 400 V (EF001392): 65 A
- Number of normally open contacts as main contact (EF001374): 3
- Rated operation power at AC-3, 400 V (EF001364): 30 kW
More info
▲BF6500A23060
Three-pole contactor, IEC operating current Ie (AC3) = 65A, AC coil 60Hz, 230VAC
Technical specifications
- Type of product:
- Contactors
- Number of poles:
- 3
- Type of coil:
- AC coil 60Hz
- Rated coil voltage [V]:
- 230
- IEC operating current Ith (AC1) [A]:
- 100
- IEC operating current and power Ie (AC3) 400V [A/Kw]:
- 65A / 30Kw
- UL/CSA horsepower ratings 480V [HP]:
- 50
- Type of mounting:
- Screw / DIN rail 35mm
| Order code | BF6500A23060 |
|---|---|
| Weight [g] | 1020 |
| Qty. per package | 1 |
| Multiple qty. of packs per order | 1 |
| Package dimensions [mm] | 141X063X120 |
| Volume [cm³] | 1066 |
| Bar code [EAN13] | 8013975223291 |
| HS Code | 85365080 |
