BF19500E110 LOVATO 3P CONTACTOR 195A AC3 48…130VAC/DC
BF19500E110
19500
LOVATO ELECTRIC
1 Pcs.
Automation > Power contactor, AC switching
Industrial Contactors and Accessories - LOVATO ELECTRIC
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Lovato Electric BF19500E110 is a high-capacity three-pole contactor engineered for heavy industrial motor control and high-current power switching. Industrial automation systems use these components to manage heavy-duty electrical loads safely and efficiently.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Voltage type for actuating (EF008242): AC/DC
- Type of electrical connection of main circuit (EF006819): Bolt connection
- Rated control supply voltage DC (EF003980): 60 V
- Rated control supply voltage AC 60 Hz (EF003979): 60 V
- Rated control supply voltage AC 50 Hz (EF003978): 60 V
- Modular version (EF001126): No
- Rated operation current Ie at AC-4, 400 V (EF008495): 95 A
- Rated operation current Ie at AC-1, 400 V (EF001393): 275 A
- Rated operation current Ie at AC-3, 400 V (EF001392): 195 A
- Number of normally open contacts as main contact (EF001374): 3
- Rated operation power at AC-3, 400 V (EF001364): 90 kW
More info
▲BF19500E110
Three-pole contactor, IEC operating current Ie (AC3) = 195A, AC/DC coil, 60…130VAC/DC
Technical specifications
- Type of product:
- Contactors
- Number of poles:
- 3
- Type of coil:
- AC/DC coil
- Rated coil voltage [V]:
- 60…130
- IEC operating current Ith (AC1) [A]:
- 275
- IEC operating current and power Ie (AC3) 400V [A/Kw]:
- 195A / 90Kw
- UL/CSA horsepower ratings 480V [HP]:
- 150
- Type of mounting:
- Screw
| Order code | BF19500E110 |
|---|---|
| Weight [g] | 3436.9 |
| Qty. per package | 1 |
| Multiple qty. of packs per order | 1 |
| Package dimensions [mm] | |
| Volume [cm³] | 8217.715 |
| Bar code [EAN13] | 8013975300381 |
| HS Code | 85365080 |
