11BG0601A400 BG0601A400 LOVATO THREE-POLE CONTACTOR, IEC OPERATING CURRENT IE (AC3) 6A, AC COIL 50/60HZ, 400..
11BG0601A400
BG0601A400
LOVATO ELECTRIC
1 Pcs.
Automation > Power contactor, AC switching
Industrial Contactors and Accessories - LOVATO ELECTRIC
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Three-pole contactor 11BG0601A400 from Lovato Electric provides reliable electromechanical switching for compact industrial automation panels and small motor controls.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Voltage type for actuating (EF008242): AC
- Type of electrical connection of main circuit (EF006819): Screw connection
- Rated control supply voltage AC 60 Hz (EF003979): 400 V
- Rated control supply voltage AC 50 Hz (EF003978): 400 V
- Modular version (EF001126): No
- Rated operation current Ie at AC-4, 400 V (EF008495): 3.3 A
- Rated operation current Ie at AC-1, 400 V (EF001393): 16 A
- Rated operation current Ie at AC-3, 400 V (EF001392): 6 A
- Number of normally open contacts as main contact (EF001374): 3
- Rated operation power at AC-3, 400 V (EF001364): 2.2 kW
More info
▲11BG0601A400
Three-pole contactor, IEC operating current Ie (AC3) = 6A, AC coil 50/60Hz, 400VAC, 1NC auxiliary contact
Technical specifications
- Type of product:
- Contactors
- Number of poles:
- 3
- Type of coil:
- AC coil 50/60Hz
- Rated coil voltage [V]:
- 400
- IEC operating current Ith (AC1) [A]:
- 16
- IEC operating current and power Ie (AC3) 400V [A/Kw]:
- 6A / 2.2Kw
- UL/CSA horsepower ratings 480V [HP]:
- 3
- Type of built-in auxiliary contacts:
- 1NC
- Type of mounting:
- Screw / DIN rail 35mm
| Order code | 11BG0601A400 |
|---|---|
| Weight [g] | 178 |
| Qty. per package | 1 |
| Multiple qty. of packs per order | 1 |
| Package dimensions [mm] | 060X045X060 |
| Volume [cm³] | 162 |
| Bar code [EAN13] | 8013975080320 |
| HS Code | 85365080 |
