LOVATO ELECTRIC 11B6300048 11B6300048 B6300048 LOVATO THREE-POLE CONTACTOR, IEC OPERATING CURRENT IE (AC3) 630A, AC/DC COIL, 48VAC/DC View larger
Images are for illustrative purposes only. Please refer to data sheet for details

11B6300048 B6300048 LOVATO THREE-POLE CONTACTOR, IEC OPERATING CURRENT IE (AC3) 630A, AC/DC COIL, 48VAC/DC

11B6300048

B6300048

LOVATO ELECTRIC

1 Pcs.

THREE-POLE CONTACTOR, IEC OPERATING CURRENT IE (AC3) = 630A, AC/DC COIL, 48VAC/DC 3P CONTACTOR B630.00 48V Three-pole contactor, IEC operating current Ie (AC3) = 630A, AC/DC coil, 48VAC/DC

Automation > Power contactor, AC switching
Industrial Contactors and Accessories - LOVATO ELECTRIC

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Lovato Electric part number 11B6300048 is a three-pole contactor designed for frequent electrical switching in industrial power systems and motor control applications. This component securely manages heavy electrical loads in automated production lines, distribution panels, and heavy machinery setups. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Voltage type for actuating (EF008242): AC/DC
  • Type of electrical connection of main circuit (EF006819): Bolt connection
  • Rated control supply voltage DC (EF003980): 48 V
  • Rated control supply voltage AC 60 Hz (EF003979): 48 V
  • Rated control supply voltage AC 50 Hz (EF003978): 48 V
  • Modular version (EF001126): No
  • Rated operation current Ie at AC-4, 400 V (EF008495): 210 A
  • Rated operation current Ie at AC-1, 400 V (EF001393): 800 A
  • Rated operation current Ie at AC-3, 400 V (EF001392): 630 A
  • Number of normally open contacts as main contact (EF001374): 3
  • Rated operation power at AC-3, 400 V (EF001364): 335 kW

More info

▲

11B6300048

Three-pole contactor, IEC operating current Ie (AC3) = 630A, AC/DC coil, 48VAC/DC

Technical specifications

Type of product:
Contactors
Number of poles:
3
Type of coil:
AC/DC coil
Rated coil voltage [V]:
48
IEC operating current Ith (AC1) [A]:
800
IEC operating current and power Ie (AC3) 400V [A/Kw]:
630A / 355Kw
Type of mounting:
Screw
Order code11B6300048
Weight [g]18400
Qty. per package1
Multiple qty. of packs per order1
Package dimensions [mm]277X203X276
Volume [cm³]15519.756
Bar code [EAN13]8013975019900
HS Code85365080

5087.57 £


Product Datasheet

Electrica Online Product Datasheet Prepared from the current product description, catalog data and structured technical attributes.
