446447 LEGRAND ARM 19" LCS3 47U 800X1000

446447

446447

LEGRAND

1 Pcs.

ARM 19" LCS3 47U 800X1000 Server Cabinets 19" LCS³ 47U 800x1000mm

Automation > Network/server enclosure
ENCLOSURES

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Legrand ARM 19" LCS3 47U 800X1000 is a high-capacity equipment rack used in data centers and telecommunications facilities to securely mount servers, switches, and patch panels. Enclosures of this type organize complex wiring layouts while providing physical protection for critical network hardware.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Rear door locking system (EF011935): Two-point
  • Front door locking system (EF011934): Two-point
  • Height (EF000040): 2200 mm
  • Degree of protection (IP) (EF005474): IP20
  • Material (EF002169): Aluminium
  • With front door (EF007377): Yes
  • Number of doors (EF000122): 2
  • Surface finishing (EF006569): Powder coated
  • Demountable (EF007551): Yes
  • With roof plate (EF007375): Yes
  • With base (EF005070): No
  • With earthing (EF007376): Yes
  • Material rear door (EF011938): Steel
  • Material front door (EF011937): Steel
  • With vertical cable management (EF011936): No
  • Max. load capacity (EF000258): 1500 kg

More info

▲
Legrand has a wide range of server cabinets and cabinets for cabling networks, with flexibility, sustainability and service as keywords. Server cabinets and network cabinets are modular in structure. Features: - Color: black RAL 9011. - Structure: Aluminium, removable. - Load capacity: 1500 kg (static). - Front door: 80% perforated front door. The door is equipped with an easy-to-assemble rotating handle and a blind plug in the lock cylinder housing. - Rear door: 80% perforated double rear doors. The door is equipped with an easy-to-assemble rotating handle and a blind plug in the lock cylinder housing. - Ceiling: 3 or 4 ceiling pre-cuts with 2 or 3 blank plates and 1 cable entry with brush, depending on the size of the cabinet. - Interior: the cabinet is equipped with 4 x 19" uprights, with height indication (U). - The front distance to the cabinet is set at 80 mm, the pitch at 740 mm. - Cable management: the cabinets are equipped with two trays for cable management. - Includes anchors for tool-free installation of the vertically mounted PDUs and anchor points for the 4 460 57 cable brackets. - Accessories: The cabinets are supplied with a set of 20 nuts and bolts. - Server cabinets are delivered without the side panels. Server cabinets with widths of 600 and 800 mm that are supplied with elements for airflow management. These elements minimize air losses, which improves the energy efficiency of the system. The rest of the specifications are the same as those of the standard servers.
Assembly LevelFront and back
Execution of the rail profileLayered
Number of doors2
Ventilation TypePassive
Width800 mm
Height2200 mm
Depth1000 mm
Modular size (standard)482.6 mm (19 inches)
Number of Height Units (AU)47
Maximum load capacity1500 kg
With ceiling plateYes
GroundedYes
With front doorYes
Front Door Materialsteel
Front door lockColon
With rear doorYes
Tailgate Materialsteel
Tailgate LockColon
With glazed doorNo
With side wallsNo
With pedestalNo
With vertical wiringNo
Materialaluminium
Surface FinishPowder coated
ColourBlack
ModelWith permanent frame
RAL number9005
AnalyzableYes
Protection Class (IP)IP20
Degree of protection (NEMA)Other
Impact resistanceIK07
Operating Temperature-10-55 °C
Storage temperature-20-55 °C
Cold aisle insulationYes
Type of cabinetServer
Front DoorOnly
Back doorDouble
Lock TypeCombination lock
