LEGRAND 433011 433011 LEGRAND CHASSIS MOD METAL 500X400 View larger
Images are for illustrative purposes only. Please refer to data sheet for details

433011 LEGRAND CHASSIS MOD METAL 500X400

433011

433011

LEGRAND

1 Pcs.

CHASSIS MOD METAL 500X400 Chassis ready to use with metal faceplates RAL 7035 for cabinets 500x400mm - 48 modules Ready-to-use modular chassis for cabinets - 500x400 - metal

Automation > Panel for distribution board
ATLANTIC-MARINA CABINETS

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

A Legrand CHASSIS MOD METAL 500X400 part 433011 serves as an internal structural enclosure chassis designed to mount modular electrical devices and circuit protection components in a centralized grid. Such metal chassis frameworks are widely integrated into industrial control panels and distribution boards to support organized wiring paths and secure DIN rail arrays. Please submit an RFQ to obtain up-to-date pricing, inventory status, and shipment lead times.

  • Height (EF000040): 500 mm
  • With cover (EF000361): Yes
  • Number of modular spacings per DIN-rail (EF001233): 16
  • Number of DIN-rails (EF001232): 3
  • With N-PE clamp (EF007962): No
  • Depth (EF000049): 132 mm
  • Type of covering (EF000339): Viewing window
  • With mounting plate (EF000118): No
  • Width (EF000008): 400 mm

More info

▲
  • Pack (number of units)1
  • Volume (dm3)25.968
  • Weight (g)3 854.00
Product characteristics
Chassis with metal faceplates RAL 7035
  • Supplied complete with 15 mm depth symmetrical rails, uprights and faceplates
  • Self extinguishing 750 °C acc. to IEC EN 60695-2-11
  • Complete height faceplates
  • Independent of the depth of the cabinets
For cabinets 500 x 400 mm
  • 48 modules (3 rows of 16)
  • Supplied with 1 blanking plate
General characteristics
Atlantic, Atlantic stainless steel and Marina cabinets - ready to use chassis
