LEGRAND 412285 412285 LEGRAND MODULE T1 25KA N-PE View larger
Images are for illustrative purposes only. Please refer to data sheet for details

412285 LEGRAND MODULE T1 25KA N-PE

412285

412285

LEGRAND

1 Pcs.

MODULE T1 25KA N-PE Plug-in replacement modules for SPD - T1+T2 - 25 kA/pole - N-PE modules Replacement cartridges for T1/25kA surge limiters (N-PE cartridge)

Automation > Surge protection device for power supply systems
MOTOR CIRCUIT BREAKERS

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

A 412285 LEGRAND MODULE T1 25KA N-PE functions as a primary protective device designed to limit transient overvoltages and protect electrical networks from high-energy lightning surges. These surge protective modules are commonly installed at the main service entrance of industrial and commercial buildings to safeguard internal power distribution equipment from catastrophic electrical disturbances.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • System configuration TN-C-S (EF009933): Yes
  • Degree of protection (IP) (EF005474): IP20
  • Nominal voltage AC (EF004220): 400 V
  • System configuration TN-S (EF009930): No
  • Construction size (EF002566): 2 modular spacing
  • System configuration other (EF009932): Yes
  • System configuration TT (EF009931): No
  • Signalling at the device (EF004241): Optic
  • Voltage protection level (EF003525): 2.5 kV
  • System configuration IT (EF009927): No
  • System configuration TN-C (EF009929): Yes
  • System configuration TN (EF009928): Yes
  • Max. continuous voltage AC (EF004198): 350 V
  • Voltage protection level N-PE (EF008796): 1.5 kV
  • Integrated backup fuse (EF008797): No
  • Voltage protection level L-N (EF004236): 1.5 kV

More info

▲
  • Pack (number of units)1
  • Volume (dm3)0.369
  • Weight (g)229.00
Product characteristics
Replacement plug-in modules
  • N-PE module for SPDs T1+T2 - 25 kA Cat.Nos 4 122 81/83 and 0 030 23
General characteristics
Class I + II (T1+T2) low voltage SPDs
  • Protection against transient overvoltagess for 230/400 V~ power networks (50/60 Hz).
  • SPDs compliant with EN/IEC 61643-11 standards
  • Recommended for main distribution boards
  • Class I+II (T1+T2) : SPDs tested and specified according to both T1 and T2 test classes
