407756 LEGRAND MAGNET DX3 6/10 KA C P+N 16A
407756
407756
LEGRAND
5 Pcs.
MAGNET DX3 6/10 KA C P+N 16A
Circuit breaker DX3 6000/10 kA - 1P+N - 230 V~ - 16 A - curve C
DX³ 6000/10kA Circuit Breaker - 1P+N - 230V~ - 16A - C curve
Automation > Miniature circuit breaker (MCB)
TERTIARY CIRCUIT BREAKERS
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
407756 LEGRAND MAGNET DX3 6/10 KA C P+N 16A produced by Legrand is a modular circuit breaker used to automatically disconnect power during electrical faults in residential and commercial panel installations.
Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Explosion-proof (EF004663): No
- Connectable conductor cross section solid-core (EF007337): 1.5 mm²
- Ambient temperature during operating (EF007515): -25 °C
- Degree of protection (IP) (EF005474): IP20
- Concurrently switching neutral conductor (EF005997): Yes
- Voltage type (EF000187): AC
- Additional equipment possible (EF008148): Yes
- Rated impulse withstand voltage Uimp (EF011980): 4 kV
- Number of protected poles (EF005548): 1
- Frequency (EF000416): 50 Hz
- Built-in depth (EF000218): 44 mm
- Number of poles (total) (EF008618): 2
- Pollution degree (EF002570): 2
- Width in number of modular spacings (EF002950): 2
- Rated insulation voltage Ui (EF001366): 500 V
- Connectable conductor cross section multi-wired (EF007343): 1.5 mm²
