077867 LEGRAND SL-PILOT BEACON LED

077867

077867

LEGRAND

1 Pcs.

SL-PILOT BEACON LED Passage lighting Soliroc - for lighting a staircase 250 V~ - IP55 - 5 modules Soliroc beacon pilot - 250V~- IK10 - IP55 - White LEDs 2W

Automation > Information light signal for domestic switching devices
SOLIROCO MECHANISMS

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

Legrand 077867 LEGRAND SL-PILOT BEACON LED is a high-visibility LED pilot beacon engineered to provide robust status signaling in demanding installation environments. Beacon units of this variety are routinely utilized on electrical distribution assemblies to alert operators to system power or operational warnings. Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Max. lamp power (EF000260): 2 W
  • Material (EF002169): Metal
  • Surface finishing (EF006569): Matt
  • Halogen free (EF000025): Yes
  • Mounting method (EF000003): Flush mounted
  • Nominal voltage (EF000002): 230 V
  • Transparent (EF006243): Yes
  • Colour light source (EF001402): White
  • Surface protection (EF000139): Metallic
  • With light source (EF005905): Yes
  • With fixed symbol/imprint (EF007949): Yes
  • With flashlight (EF006575): No
  • Suitable for degree of protection (IP) (EF006755): IP55
  • Device depth (EF008810): 49 mm
  • Device width (EF008808): 181 mm
  • Assembly arrangement (EF000005): Complete device

More info

▲
  • Pack (number of units)1
  • Volume (dm3)1.189
  • Weight (g)465.00
Product characteristics
Passage lighting - IK 10 - IP 55
  • For lighting a staircase, etc 250 V~
  • Supplied complete with :
    • Soliroc plate 5 modules
    • 1 set of 4 blanking plates that can be removed by drilling
  • Mechanism: screw fixing in flush-mounting boxes, depth 40 mm
  • Supplied with :
    • 16 white LEDs (2 W)
    • 1 x 5 modules Batibox support
General characteristics
Soliroc™ - control mechanisms IK 10
  • Suitable for public buildings, unsupervised passageways, car parks, communal areas in buildings
  • High resistance to IK 10 impacts and humidity
  • 4 fixing points by plugging the plate directly on the wall and 4 blanking plates to be force-mounted on the plate (can only be removed by drilling)
  • Mechanisms supplied with cover plates, to be equipped with support frames and plates
