View larger
Images are for illustrative purposes only. Please refer to data sheet for details
063442 LEGRAND FEEDING ADDITIONAL 27VCC
063442
063442
LEGRAND
1 Pcs.
FEEDING ADDITIONAL 27VCC
Scenario scheduler power supply - home system management BUS/SCS - 2 DIN modules
Additional 27VDC power supply
Automation > DC-power supply
PRESCRIPTION OF EMERGENCIES
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲- Pack (number of units)1
- Volume (dm3)0.369
- Weight (g)136.00
Product characteristics
Additional power supply- Power supply 220-240 V - 50/60 Hz
- Output 1-2 27 VDC - 600 mA
- Dim.: 2 x 17.5 mm modules
- New Cat.No 3 460 20
General characteristics
LVS2 (Legrand Vision System) - addressable and monitoring system| Feature Name | Feature Value |
|---|---|
| Power output (EF003034) | 16.2 W |
| Height (EF000040) | 89.7 mm |
| Degree of protection (IP) (EF005474) | IP30 |
| Wall mounting possible (EF003973) | No |
| Suitable for safety functions (EF001597) | No |
| Suitable for rail mounting (EF003972) | Yes |
| Output voltage stabilized (EF003092) | Yes |
| Rated supply voltage AC 50 Hz (EF007076) | 220 V |
| Rated supply voltage AC 60 Hz (EF007077) | 220 V |
| Short-circuit-proof (EF007332) | Yes |
| Max. output current 1 (EF008284) | 0.6 A |
| Modular version (EF001126) | Yes |
| Voltage type (supply voltage) (EF002991) | DC |
| Width in number of modular spacings (EF002950) | 2 |
| Direct mounting possible (EF005689) | No |
| Stabilized (EF005302) | Yes |
| Type of electric connection (EF003961) | Screw connection |
| 1st secondary output voltage (EF006792) | 26.9 V |
| Secondary voltage adjustable (EF007002) | No |
| Depth (EF000049) | 66.2 mm |
| Power consumption (EF000346) | 41.8 VA |
| Width (EF000008) | 33.9 mm |
