036910 LEGRAND ARM METAL ATLANTIC 300X200X160
036910
036910
LEGRAND
1 Pcs.
Automation > Empty cabinet
ATLANTIC-MARINA CABINETS
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Metal cabinet 036910 from Legrand functions as a secure wall-mounted enclosure for housing electrical distribution equipment, automation gear, and terminal assemblies against harsh environmental factors.
Industrial facilities utilize such steel housings to organize control wiring and protect sensitive electrical devices from dust, liquid ingress, and unauthorized access. Pricing, availability and lead time are confirmed per enquiry through an RFQ.
- Height (EF000040): 300 mm
- Type of door (EF004464): Single
- Degree of protection (IP) (EF005474): IP66
- Inner depth (EF001131): 140 mm
- Transparent cover/door (EF006244): No
- Housing material (EF001596): Steel
- With lock (EF006306): Yes
- Mounting method (EF000003): Surface mounted
- Suitable for outdoor use (EF003532): Yes
- Number of openings for flange plates (EF009554): 1
- Cover model (EF009212): Closed
- Material plate thickness cabinet (EF009170): 1 mm
- Material plate thickness door/cover (EF009171): 1.25 mm
- Surface protection (EF000139): Powder coated
- RAL-number (EF000116): 7035
- Built-in depth (EF000218): 165 mm
More info
▲| Mounting method | Surface mounted |
|---|---|
| Type of covering | Door |
| Cover model | Closed |
| Type of door | Single |
| Transparent cover/door | No |
| With lock | Yes |
| Height | 300 mm |
| Width | 200 mm |
| Depth | 160 mm |
| Built-in depth | 165 mm |
| Inner depth | 140 mm |
| Material plate thickness cabinet | 1 mm |
| Material plate thickness door/cover | 1.25 mm |
| Colour | Grey |
|---|---|
| RAL-number | 7035 |
| Number of openings for flange plates | 1 |
| Extension possible | No |
| Housing material | Steel |
| Surface protection | Powder coating |
| With mounting plate | Yes |
| Suitable for outdoor use | Yes |
| Suitable for lightning protection | No |
| Degree of protection (IP) | IP66 |
| Protection class according to IEC 61140 | I |
| degree of impact strength (IK) | IK10 |
| Circuit integrity | Other |
