034042 LEGRAND TERMINALS CLICK 2X16 MM2
034042
034042
LEGRAND
20 Pcs.
Automation > Single- and multi-pole terminal strip
STEP TERMINALS AND TERMINALS
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
Request a Quote
Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.
Request QuoteProduct Overview
Legrand terminals click 2x16 mm2 (034042) provide a streamlined click-mounting connection point for high-current power distribution inside electrical enclosures. These terminal blocks are commonly integrated into switchgear assemblies to ensure rapid installation and secure conductor retention. Pricing, availability, and lead time are confirmed per enquiry through an RFQ.
- Connectable conductor cross section solid-core (EF007337): 16 mm²
- Height (EF000040): 41 mm
- Material insulation body (EF007543): Thermoplastic
- Connectable conductor cross section multi-wired (EF007343): 16 mm²
- Explosion-tested version 'Ex e' (EF008498): No
- Transparent (EF006243): No
- Operating temperature (EF002393): -5 °C
- Rated current In (EF008250): 119 A
- Number of poles (EF001391): 1
- Closing plate required (EF002525): No
- Depth (EF000049): 22.3 mm
- Colour (EF000007): Black
- Width (EF000008): 46 mm
- Number of clamp positions per pole (EF002519): 1
- Rated voltage (EF000228): 230 V
- Type of electrical connection 2 (EF002527): Screw connection
More info
▲| Explosion-tested version 'Ex e' | No |
|---|---|
| Connectable conductor cross section fine-strand without cable end sleeve | 18-18 mm² |
| Connectable conductor cross section fine-strand with cable end sleeve | 10-10 mm² |
| Connectable conductor cross section solid-core | 16-16 mm² |
| Connectable conductor cross section multi-wired | 16-16 mm² |
| Rated current In | 119 A |
| Rated voltage | 230 V |
| Type of electrical connection 1 | Other |
| Type of electrical connection 2 | Screw connection |
| Number of poles | 1 |
| Number of clamp positions per pole | 1 |
| Mounting method | Other |
|---|---|
| Material insulation body | Thermoplastic |
| Operating temperature | -5-40 °C |
| Inflammability class of insulation material according to UL94 | Other |
| Width | 46 mm |
| Height | 41 mm |
| Depth | 22.3 mm |
| Closing plate required | No |
| Colour | Black |
| Transparent | No |
