LEGRAND 021137 021137 LEGRAND XL3 STUDS FUNCTIONAL View larger
Images are for illustrative purposes only. Please refer to data sheet for details

021137 LEGRAND XL3 STUDS FUNCTIONAL

021137

021137

LEGRAND

1 Pcs.

XL3 STUDS FUNCTIONAL Functionnal uprights (x2) for XL³ 6300 enclosure - for fixing mounting equipment Functional upright (x2) for XL³ 6300 cabinet

Automation > Component for installation (switchgear cabinet)
XL3 800-4000 ENERGY DISTRIBUTION CABINETS

Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.

Request a Quote

Pricing and availability are confirmed for each enquiry. Send this part and we will reply with price and lead time.

Request Quote

Product Overview

The Legrand 021137 functional studs provide specialized mounting and anchoring points within XL3 enclosure systems. Such hardware components are regularly utilized by panel builders to secure internal chassis plates, busbar supports, and structural dividers efficiently.

Pricing, availability and lead time are confirmed per enquiry through an RFQ.

  • Height (EF000040): 2200 mm
  • Material (EF002169): Metal
  • Suitable for enclosure building height (EF009583): 2200 mm

More info

▲
  • Pack (number of units)1
  • Volume (dm3)48.279
  • Weight (g)30 100.00
Product characteristics
Equipment
Functional uprights
  • For fixing mounting equipment (faceplate, rails…)
  • Set of 2 functional uprights
General characteristics
Distribution enclosures XL³ 6300
  • IP 30 - IK 07
  • Consist of the combination of a "roof-base" assembly, structural uprights, rear and side panels RAL 7035, plinths RAL 7004
  • Height 2200 mm, usable faceplate height 2000 mm
