View larger
Images are for illustrative purposes only. Please refer to data sheet for details
021133 LEGRAND XL3 BASE+ROOF ANCH1425 PRF475
021133
021133
LEGRAND
1 Pcs.
XL3 BASE+ROOF ANCH1425 PRF475
Roof base for XL³ 6300 enclosure - D. 475 x W. 1300 mm
Ceiling - base for XL³ 6300 cabinet - 1425x475mm
Automation > Top-/floor cover element (enclosure/switchgear cabinet)
XL3 800-4000 ENERGY DISTRIBUTION CABINETS
Product condition, packaging, certifications and applicable manufacturer warranty terms are confirmed with the quotation.
More info
▲- Pack (number of units)1
- Volume (dm3)216.00
- Weight (g)47 600.00
Product characteristics
Enclosures modular metalRoof-base for enclosure
- Fitted with cable entry plates
- Take the structural uprights
- Depth : 475 mm
- Width external : 1425 mm
- Width usable : 1300 mm
General characteristics
Distribution enclosures XL³ 6300- IP 30 - IK 07
- Consist of the combination of a "roof-base" assembly, structural uprights, rear and side panels RAL 7035, plinths RAL 7004
- Height 2200 mm, usable faceplate height 2000 mm
| Feature Name | Feature Value |
|---|---|
| Suitable for outdoor set-up (EF005774) | No |
| Height (EF000040) | 150 mm |
| Material (EF002169) | Steel |
| Surface finishing (EF006569) | Powder coated |
| Suitable for bottom planking (EF009585) | Yes |
| Suitable for roof planking (EF009584) | Yes |
| With de-aeration (EF001161) | No |
| Depth (EF000049) | 475 mm |
| Colour (EF000007) | Grey |
| Suitable for enclosure building width (EF000326) | 1425 mm |
| RAL-number (EF000116) | 7029 |
| With cable entry (EF000325) | Yes |
| Suitable for enclosure building depth (EF000327) | 475 mm |
| Width (EF000008) | 1425 mm |
